Specification: Model I9-14900F Product Collection Intel® Core™ I9 Processors (14Th Gen) Code Name Products Formerly Raptor Lake Vertical Segment Desktop Lithography Intel 7 Use Conditions Pc/Client/Tablet Cpu Specifications Total Cores 24 # Of Performance
| Model | I9-14900F |
| Product Collection | Intel® Core™ I9 Processors (14Th Gen) |
| Code Name | Products Formerly Raptor Lake |
| Vertical Segment | Desktop |
| Lithography | Intel 7 |
| Use Conditions | Pc/Client/Tablet |
| Cpu Specifications | |
| Total Cores | 24 |
| # Of Performance-Cores | 8 |
| # Of Efficient-Cores | 16 |
| Total Threads | 32 |
| Max Turbo Frequency | 5.8 Ghz |
| Intel® Thermal Velocity Boost Frequency | 5.8 Ghz |
| Intel® Turbo Boost Max Technology 3.0 Frequency ‡ | 5.6 Ghz |
| Performance-Core Max Turbo Frequency | 5.4 Ghz |
| Efficient-Core Max Turbo Frequency | 4.3 Ghz |
| Performance-Core Base Frequency | 2 Ghz |
| Efficient-Core Base Frequency | 1.5 Ghz |
| Cache | 36 Mb Intel® Smart Cache |
| Total L2 Cache | 32 Mb |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 219 W |
| Memory Specifications | |
| Max Memory Size (Dependent On Memory Type) | 192 Gb |
| Memory Types | Up To Ddr5 5600 Mt/S Up To Ddr4 3200 Mt/S |
| Max # Of Memory Channels | 2 |
| Max Memory Bandwidth | 89.6 Gb/S |
| Expansion Options | |
| Direct Media Interface (Dmi) Revision | 4.0 |
| Max # Of Dmi Lanes | 8 |
| Scalability | 1S Only |
| Pci Express Revision | 5.0 And 4.0 |
| Pci Express Configurations ‡ | Up To 1X16+4, 2X8+4 |
| Max # Of Pci Express Lanes | 20 |
| Package Specifications | |
| Sockets Supported | Fclga1700 |
| Max Cpu Configuration | 1 |
| Thermal Solution Specification | Pcg 2020C |
| Tjunction | 100°C |
| Package Size | 45.0 Mm X 37.5 Mm |
| Advanced Technologies | |
| Intel® Gaussian &Amp; Neural Accelerator | 3.0 |
| Intel® Thread Director | Yes |
| Intel® Deep Learning Boost (Intel® Dl Boost) On Cpu | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Adaptive Boost Technology | Yes |
| Intel® Thermal Velocity Boost | Yes |
| Intel® Turbo Boost Max Technology 3.0 ‡ | Yes |
| Intel® Turbo Boost Technology ‡ | 2.0 |
| Intel® Hyper-Threading Technology ‡ | Yes |
| Intel® 64 ‡ | Yes |
| Instruction Set | 64-Bit |
| Instruction Set Extensions | Intel® Sse4.1, Intel® Sse4.2, Intel® Avx2 |
| Idle States | Yes |
| Enhanced Intel Speedstep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Volume Management Device (Vmd) | Yes |
| Security &Amp; Reliability | |
| Intel® Standard Manageability (Ism) | Yes |
| Intel® Control-Flow Enforcement Technology | Yes |
| Intel® Aes New Instructions | Yes |
| Secure Key | Yes |
| Intel® Os Guard | Yes |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
| Mode-Based Execute Control (Mbec) | Yes |
| Intel® Virtualization Technology (Vt-X) | Yes |
| Intel® Virtualization Technology For Directed I/O (Vt-D) | Yes |
| Intel® Vt-X With Extended Page Tables (Ept) | Yes |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications Are Subject To Change Without Notice. |
| Model | I9-14900F |
| Product Collection | Intel® Core™ I9 Processors (14Th Gen) |
| Code Name | Products Formerly Raptor Lake |
| Vertical Segment | Desktop |
| Lithography | Intel 7 |
| Use Conditions | Pc/Client/Tablet |
| Cpu Specifications | |
| Total Cores | 24 |
| # Of Performance-Cores | 8 |
| # Of Efficient-Cores | 16 |
| Total Threads | 32 |
| Max Turbo Frequency | 5.8 Ghz |
| Intel® Thermal Velocity Boost Frequency | 5.8 Ghz |
| Intel® Turbo Boost Max Technology 3.0 Frequency ‡ | 5.6 Ghz |
| Performance-Core Max Turbo Frequency | 5.4 Ghz |
| Efficient-Core Max Turbo Frequency | 4.3 Ghz |
| Performance-Core Base Frequency | 2 Ghz |
| Efficient-Core Base Frequency | 1.5 Ghz |
| Cache | 36 Mb Intel® Smart Cache |
| Total L2 Cache | 32 Mb |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 219 W |
| Memory Specifications | |
| Max Memory Size (Dependent On Memory Type) | 192 Gb |
| Memory Types | Up To Ddr5 5600 Mt/S Up To Ddr4 3200 Mt/S |
| Max # Of Memory Channels | 2 |
| Max Memory Bandwidth | 89.6 Gb/S |
| Expansion Options | |
| Direct Media Interface (Dmi) Revision | 4.0 |
| Max # Of Dmi Lanes | 8 |
| Scalability | 1S Only |
| Pci Express Revision | 5.0 And 4.0 |
| Pci Express Configurations ‡ | Up To 1X16+4, 2X8+4 |
| Max # Of Pci Express Lanes | 20 |
| Package Specifications | |
| Sockets Supported | Fclga1700 |
| Max Cpu Configuration | 1 |
| Thermal Solution Specification | Pcg 2020C |
| Tjunction | 100°C |
| Package Size | 45.0 Mm X 37.5 Mm |
| Advanced Technologies | |
| Intel® Gaussian &Amp; Neural Accelerator | 3.0 |
| Intel® Thread Director | Yes |
| Intel® Deep Learning Boost (Intel® Dl Boost) On Cpu | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Adaptive Boost Technology | Yes |
| Intel® Thermal Velocity Boost | Yes |
| Intel® Turbo Boost Max Technology 3.0 ‡ | Yes |
| Intel® Turbo Boost Technology ‡ | 2.0 |
| Intel® Hyper-Threading Technology ‡ | Yes |
| Intel® 64 ‡ | Yes |
| Instruction Set | 64-Bit |
| Instruction Set Extensions | Intel® Sse4.1, Intel® Sse4.2, Intel® Avx2 |
| Idle States | Yes |
| Enhanced Intel Speedstep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Volume Management Device (Vmd) | Yes |
| Security &Amp; Reliability | |
| Intel® Standard Manageability (Ism) | Yes |
| Intel® Control-Flow Enforcement Technology | Yes |
| Intel® Aes New Instructions | Yes |
| Secure Key | Yes |
| Intel® Os Guard | Yes |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
| Mode-Based Execute Control (Mbec) | Yes |
| Intel® Virtualization Technology (Vt-X) | Yes |
| Intel® Virtualization Technology For Directed I/O (Vt-D) | Yes |
| Intel® Vt-X With Extended Page Tables (Ept) | Yes |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications Are Subject To Change Without Notice. |
