Features Engineered Using The Latest Technology I5-10400 Intel Core I5-10400 Processor (12M Cache, Up To 4.30 Ghz) Intel Core I5-10400 Processor (12M Cache, Up To 4.30 Ghz)10Th Generation Intel Core I5 Processorsproducts Formerly Comet Lakeprocessor Base
Features
Specifications
| Essentials | |
| Product Collection | 10Th Generation Intel Core, I5 Processors |
| Code Name | Products Formerly Comet Lake |
| Vertical Segment | Desktop |
| Processor Number | I5-10400 |
| Status | Launched |
| Launch Date | Q2’20 |
| Lithography | 14 Nm |
| Use Conditions | Pc/Client/Tablet |
| Cpu Specifications | |
| Total Cores | 6 |
| Total Threads | 12 |
| Max Turbo Frequency | 4.30 Ghz |
| Intel Turbo Boost Technology 2.0 Frequency | 4.30 Ghz |
| Processor Base Frequency | 2.90 Ghz |
| Cache | 12 Mb Intel Smart Cache |
| Bus Speed | 8 Gt/S |
| Tdp | 65 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Datasheet | View Now |
| Memory Specifications | |
| Max Memory Size (Dependent On Memory Type) | 128 Gb |
| Memory Types | Ddr4-2666 |
| Max # Of Memory Channels | 2 |
| Max Memory Bandwidth | 41.6 Gb/S |
| Ecc Memory Supported | No |
| Processor Graphics | |
| Processor Graphics | Intel Uhd Graphics 630 |
| Graphics Base Frequency | 350 Mhz |
| Graphics Max Dynamic Frequency | 1.10 Ghz |
| Graphics Video Max Memory | 64 Gb |
| 4K Support | Yes | At 60Hz |
| Max Resolution (Hdmi) | 4096 X 2160@30Hz |
| Max Resolution (Dp) | 4096 X 2304@60Hz |
| Max Resolution (Edp – Integrated Flat Panel) | 4096 X 2304@60Hz |
| Directx* Support | 12 |
| Opengl* Support | 4.5 |
| Intel Quick Sync Video | Yes |
| Intel Intru 3D Technology | Yes |
| Intel Clear Video Hd Technology | Yes |
| Intel Clear Video Technology | Yes |
| # Of Displays Supported | 3 |
| Device Id | 0X9Bc8 / 0X9Bc5 |
| Expansion Options | |
| Scalability | 1S Only |
| Pci Express Revision | 3 |
| Pci Express Configurations ‡ | Up To 1X16 | 2X8 | 1X8+2X4 |
| Max # Of Pci Express Lanes | 16 |
| Package Specifications | |
| Sockets Supported | Fclga1200 |
| Max Cpu Configuration | 1 |
| Thermal Solution Specification | Pcg 2015C |
| Tjunction | 100∞C |
| Package Size | 37.5Mm X 37.5Mm |
| Advanced Technologies | |
| Intel Optane Memory Supported | Yes |
| Intel Thermal Velocity Boost | No |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel Turbo Boost Technology | 2 |
| Intel Vpro Platform Eligibility | No |
| Intel Hyper-Threading Technology | Yes |
| Intel Virtualization Technology (Vt-X) | Yes |
| Intel Virtualization Technology For Directed I/O (Vt-D) | Yes |
| Intel Vt-X With Extended Page Tables (Ept) | Yes |
| Intel Transactional Synchronization Extensions | No |
| Intel 64 | Yes |
| Instruction Set | 64-Bit |
| Instruction Set Extensions | Intel Sse4.1 | Intel Sse4.2 | Intel Avx2 |
| Idle States | Yes |
| Enhanced Intel Speed Step Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel Identity Protection Technology | Yes |
| Intel Stable It Platform Program (Sipp) | No |
| Security &Amp; Reliability | |
| Intel Aes New Instructions | Yes |
| Secure Key | Yes |
| Intel Software Guard Extensions (Intel Sgx) | Yes With Intel Me |
| Intel Os Guard | Yes |
| Intel Trusted Execution Technology | No |
| Execute Disable Bit | Yes |
| Intel Boot Guard | Yes |
| Warranty | 3 Years |
Features
Specifications
| Essentials | |
| Product Collection | 10Th Generation Intel Core, I5 Processors |
| Code Name | Products Formerly Comet Lake |
| Vertical Segment | Desktop |
| Processor Number | I5-10400 |
| Status | Launched |
| Launch Date | Q2’20 |
| Lithography | 14 Nm |
| Use Conditions | Pc/Client/Tablet |
| Cpu Specifications | |
| Total Cores | 6 |
| Total Threads | 12 |
| Max Turbo Frequency | 4.30 Ghz |
| Intel Turbo Boost Technology 2.0 Frequency | 4.30 Ghz |
| Processor Base Frequency | 2.90 Ghz |
| Cache | 12 Mb Intel Smart Cache |
| Bus Speed | 8 Gt/S |
| Tdp | 65 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Datasheet | View Now |
| Memory Specifications | |
| Max Memory Size (Dependent On Memory Type) | 128 Gb |
| Memory Types | Ddr4-2666 |
| Max # Of Memory Channels | 2 |
| Max Memory Bandwidth | 41.6 Gb/S |
| Ecc Memory Supported | No |
| Processor Graphics | |
| Processor Graphics | Intel Uhd Graphics 630 |
| Graphics Base Frequency | 350 Mhz |
| Graphics Max Dynamic Frequency | 1.10 Ghz |
| Graphics Video Max Memory | 64 Gb |
| 4K Support | Yes | At 60Hz |
| Max Resolution (Hdmi) | 4096 X 2160@30Hz |
| Max Resolution (Dp) | 4096 X 2304@60Hz |
| Max Resolution (Edp – Integrated Flat Panel) | 4096 X 2304@60Hz |
| Directx* Support | 12 |
| Opengl* Support | 4.5 |
| Intel Quick Sync Video | Yes |
| Intel Intru 3D Technology | Yes |
| Intel Clear Video Hd Technology | Yes |
| Intel Clear Video Technology | Yes |
| # Of Displays Supported | 3 |
| Device Id | 0X9Bc8 / 0X9Bc5 |
| Expansion Options | |
| Scalability | 1S Only |
| Pci Express Revision | 3 |
| Pci Express Configurations ‡ | Up To 1X16 | 2X8 | 1X8+2X4 |
| Max # Of Pci Express Lanes | 16 |
| Package Specifications | |
| Sockets Supported | Fclga1200 |
| Max Cpu Configuration | 1 |
| Thermal Solution Specification | Pcg 2015C |
| Tjunction | 100∞C |
| Package Size | 37.5Mm X 37.5Mm |
| Advanced Technologies | |
| Intel Optane Memory Supported | Yes |
| Intel Thermal Velocity Boost | No |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel Turbo Boost Technology | 2 |
| Intel Vpro Platform Eligibility | No |
| Intel Hyper-Threading Technology | Yes |
| Intel Virtualization Technology (Vt-X) | Yes |
| Intel Virtualization Technology For Directed I/O (Vt-D) | Yes |
| Intel Vt-X With Extended Page Tables (Ept) | Yes |
| Intel Transactional Synchronization Extensions | No |
| Intel 64 | Yes |
| Instruction Set | 64-Bit |
| Instruction Set Extensions | Intel Sse4.1 | Intel Sse4.2 | Intel Avx2 |
| Idle States | Yes |
| Enhanced Intel Speed Step Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel Identity Protection Technology | Yes |
| Intel Stable It Platform Program (Sipp) | No |
| Security &Amp; Reliability | |
| Intel Aes New Instructions | Yes |
| Secure Key | Yes |
| Intel Software Guard Extensions (Intel Sgx) | Yes With Intel Me |
| Intel Os Guard | Yes |
| Intel Trusted Execution Technology | No |
| Execute Disable Bit | Yes |
| Intel Boot Guard | Yes |
| Warranty | 3 Years |
