Chipset |
Amd X870
|
|---|
Cpu |
Supports Amd Ryzen„ 9000/ 8000/ 7000 Series Desktop Processors
Socket Am5
|
|---|
Memory |
4X Ddr5 Udimm, Maximum Memory Capacity 256Gb
Memory Support Ddr5 8400 – 5600 (Oc) Mt/S / 5600 – 4800 (Jedec) Mt/S
Ryzen„ 9000 Series Processors Max. Overclocking Frequency:
€ 1Dpc 1R Max Speed Up To 8400+ Mt/S
€ 1Dpc 2R Max Speed Up To 6400+ Mt/S
€ 2Dpc 1R Max Speed Up To 6400+ Mt/S
€ 2Dpc 2R Max Speed Up To 4800+ Mt/S
Supports Amd Por Speed And Jedec Speed
Supports Memory Overclocking And Amd Expo„
Supports Dual-Channel Mode
Supports Non-Ecc, Un-Buffered Memory
Supports Cudimm, Clock Driver Bypass Mode Only*
* Cudimm Support And Por Boot Frequency May Vary By Cpu Series, With Manual Overclocking Available After Boot. Certain Cpus May Fail To Boot, But Future Bios Updates Will Improve Compatibility.
€ The Dimm Slots On This Motherboard Have Double-Sided Latches.
€ Memory Compatibility And Supported Speeds Can Vary Depending On The Cpu And Memory Configuration. For Detailed Information, Please Refer To The Memory Compatibility List Available On The Product€™S Support Page Or Visit Https://Www.Msi.Com/Support/.
|
|---|
Onboard Graphics |
1X Hdmi„
Support Hdmi„ 2.1 Frl, Maximum Resolution Of 8K 60Hz*
2X Type-C Displayport
Usb4Port, Supporting Displayport 1.4 With Hbr3 Over Usb Type-C, Maximum Resolution Of 4K 60Hz*
*Available Only On Processors Featuring Integrated Graphics. Graphics Specifications May Vary Depending On The Cpu Installed.
|
|---|
Slot |
3X Pci-E X16 Slot
Pci_E1 Gen Pcie 5.0 Supports Up To X16 (From Cpu)
Pci_E2 Gen Pcie 3.0 Supports Up To X1 (From Chipset)
Pci_E3 Gen Pcie 4.0 Supports Up To X4 (From Chipset)
Pci_E1 Slot
€ Supports Pcie 5.0 X16 (For Ryzen„ 9000/ 7000 Series Processors)
€ Supports Pcie 4.0 X8 (For Ryzen„ 8700/ 8600/ 8400 Series Processors)
€ Supports Pcie 4.0 X4 (For Ryzen„ 8500/ 8300 Series Processor)
*Pci_E3 Slot Will Run At X2 Speed When Installing Device In The M2_3 Slot. You Can Switch Pci_E3 Slot To X4 In The Bios, But This Will Disable The M2_3 Slot
|
|---|
Audio |
RealtekAlc4080 Codec
7.1-Channel Usb High Performance Audio
Supports Up To 32-Bit/384Khz Playback On Front Panel
Supports S/Pdif Output
|
|---|
Storage |
4X M.2
M.2_1 Source (From Cpu) Supports Up To Pcie 5.0 X4 , Supports 22110/2280 Devices
M.2_2 Source (From Cpu) Supports Up To Pcie 5.0 X4 , Supports 2280/2260 Devices
M.2_3 Source (From Chipset) Supports Up To Pcie 4.0 X2 , Supports 2280/2260 Devices
M.2_4 Source (From Chipset) Supports Up To Pcie 4.0 X4 , Supports 2280/2260 Devices
4X Sata 6G
M2_1 &Amp; M2_2 Slots
€ Supports Up To Pcie 5.0 X4 (For Ryzen„ 9000/ 7000 Series Processors)
€ Supports Up To Pcie 4.0 X4 (For Ryzen„ 8000 Series Processors)
* The M2_2 Slot Will Be Unavailable When Using Ryzen„ 8500/ 8300 Series Processors.
** Usb 40Gbps Type-C Ports On The Back Panel And M2_2 Slot Share Pcie 5.0 X4 Bandwidth. Both Run At Pcie 5.0 X2 When A Device Is Installed In The M2_2 Slot. You Can Switch M2_2 To Pcie 5.0 X4 In The Bios, But This Will Disable The Usb 40Gbps Type-C Ports
*** Pci_E3 Slot Will Run At X2 Speed When Installing Device In The M2_3 Slot. You Can Switch Pci_E3 Slot To X4 In The Bios, But This Will Disable The M2_3 Slot.
**** Please Refer To The Manual For M.2 Ssd Heatsink Restrictions
|
|---|
Multi-Gpu |
Amd Multi-Gpu Support
|
|---|
Raid |
Supports Raid 0, Raid 1 And Raid 10 For M.2 Nvme Storage Devices
|
|---|
Usb |
4X Usb 2.0 (Rear)
4X Usb 2.0 (Front)
3X Usb 5Gbps Type A (Rear)
4X Usb 5Gbps Type A (Front)
2X Usb 10Gbps Type A (Rear)
1X Usb 10Gbps Type C (Rear)
1X Usb 20Gbps Type C (Front)
2X Usb 40Gbps Type C (Rear)
|
|---|
Lan |
Realtek8126-Cg 5G Lan
|
|---|
Internal Io |
1X Power Connector(Atx_Pwr)
2X Power Connector(Cpu_Pwr)
1X Power Connector(Pcie_Pwr 8Pin)
1X Cpu Fan
1X Combo Fan (Pump_Sys Fan)
6X System Fan
1X Ez Conn-Header (Jaf_2)
2X Front Panel (Jfp)
1X Chassis Intrusion (Jci)
1X Front Audio (Jaud)
3X Addressable V2 Rgb Led Connector (Jargb_V2)
1X Rgb Led Connector(Jrgb)
1X Tpm Pin Header(Support Tpm 2.0)
4X Usb 2.0 Ports
4X Usb 5Gbps Type A Ports
1X Usb 20Gbps Type C Ports
|
|---|
Wireless Lan &Amp; Bluetooth |
Wi-Fi 7
The Wireless Module Is Pre-Installed In The M.2 (Key-E) Slot
Supports Mu-Mimo Tx/Rx, 2.4Ghz/ 5Ghz/ 6Ghz* (320Mhz) Up To 5.8Gbps
Supports 802.11 A/ B/ G/ N/ Ac/ Ax/ Be
Supports Bluetooth5.4**, Mlo, 4Kqam
* 6Ghz Band Support May Depend On Every Country€™S Regulations And Wi-Fi 7 Will Be Ready In Windows 11 Version 24H2.
** The Bluetooth Version May Be Updated, Please Refer To The Wi-Fi Chipset Vendor€™S Website For Details. Bluetooth 5.4 Will Be Ready In Windows 11 Version 24H2.
|
|---|
Led Feature |
4X Ez Debug Led
1X Ez Digit Debug Led
|
|---|
Back Panel Ports |
- Clear Cmos Button
- Usb 10Gbps Type-A
- Usb 5Gbps Type-A
- Usb 2.0
- 5G Lan
- Wi-Fi / Bluetooth
- Audio Connectors
- Flash Bios Button
- Hdmi„
- Usb 40Gbps Type-C
- Usb 10Gbps Type-C
- Usb 10Gbps Type-A
|
|---|
Operating System |
Support For Windows11 64-Bit |
|---|
