Specifications Essentials Product Collection 11Th Generation Intel Coreô I7 Processors Code Name Products Formerly Rocket Lake Vertical Segment Desktop Processor Number I7-11700 Lithography 14 Nm Use Conditions Pc/Client/Tablet Performance Specifications
Specifications
| Essentials | |
| Product Collection | 11Th Generation Intel Coreô I7 Processors |
| Code Name | Products Formerly Rocket Lake |
| Vertical Segment | Desktop |
| Processor Number | I7-11700 |
| Lithography | 14 Nm |
| Use Conditions | Pc/Client/Tablet |
| Performance Specifications | |
| Cores | 8 |
| Threads | 16 |
| Processor Base Frequency | 2.50 Ghz |
| Max Turbo Frequency | 4.90 Ghz |
| Cache | 16 Mb Intel Smart Cache |
| Bus Speed | 8 Gt/S |
| Intel Turbo Boost Max Technology 3.0 Frequency | 4.90 Ghz |
| Intel Turbo Boost Technology 2.0 Frequency | 4.80 Ghz |
| Tdp | 65 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (Dependent On Memory Type) | 128 Gb |
| Memory Types | Ddr4-3200 |
| Max Memory Channels | 2 |
| Max Memory Bandwidth | 50.0 Gb/S |
| Ecc Memory Supported | No |
| Processor Graphics | |
| Processor Graphics | Intel Uhd Graphics 750 |
| Graphics Base Frequency | 350 Mhz |
| Graphics Max Dynamic Frequency | 1.30 Ghz |
| Graphics Video Max Memory | 64 Gb |
| Execution Unit | 32 |
| 4K Support | Yes, At 60Hz |
| Max Resolution (Hdmi) | 4096X2160@30Hz |
| Max Resolution (Dp) | 5120X3200@60Hz |
| Max Resolution (Edp – Integrated Flat Panel) | 5120X3200@60Hz |
| Directx Support | 12.1 |
| Opengl Support | 4.5 |
| Intel Quick Sync Video | Yes |
| Intel Intru 3D Technology | Yes |
| Intel Clear Video Hd Technology | Yes |
| Intel Clear Video Technology | Yes |
| Displays Supported | 3 |
| Device Id | 0X4C8A |
| Open Cl Support | 3.0 |
| Expansion Options | |
| Scalability | 1S Only |
| Pci Express Revision | 4.0 |
| Pci Express Configurations | Up To 1X16+1X4, 2X8+1X4, 1X8+3X4 |
| Max Pci Express Lanes | 20 |
| Package Specifications | |
| Socket Supported | Fclga1200 |
| Max Cpu Configuration | 1 |
| Thermal Solution Specification | Pcg 2019A |
| Tjunction | 100∞C |
| Package Size | 37.5 Mm X 37.5 Mm |
| Advanced Technologies | |
| Intel Deep Learning Boost (Intel Dl Boost) | Yes |
| Intel Thermal Velocity Boost | No |
| Intel Turbo Boost Max Technology 3.0 | Yes |
| Intel Turbo Boost Technology | 2.0 |
| Intel Vpro Platform Eligibility | Yes |
| Intel Hyper-Threading Technology | Yes |
| Intel Virtualization Technology (Vt-X) | Yes |
| Intel Virtualization Technology For Directed I/O (Vt-D) | Yes |
| Intel Vt-X With Extended Page Tables (Ept) | Yes |
| Intel 64 | Yes |
| Instruction Set | 64-Bit |
| Instruction Set Extensions | Intel Sse4.1, Intel Sse4.2, Intel Avx2, Intel Avx-512 |
| Idle States | Yes |
| Enhanced Intel Speedstep Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel Identity Protection Technology | Yes |
| Intel Stable Image Platform Program (Sipp) | Yes |
| Intel Gaussian And Neural Accelerator 2.0 | Yes |
| Security &Amp; Reliability | |
| Intel Aes New Instructions | Yes |
| Secure Key | Yes |
| Intel Software Guard Extensions (Intel Sgx) | No |
| Intel Os Guard | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel Boot Guard | Yes |
| Warranty | 3 Years |
