Specifications Bearing Type Fluid Dynamic Bearing Fan Air Pressure 1.62 mmAq Fan Airflow 59.46 CFM Fan Connector 4-pin PWM Fan Dimensions 120×120×25 mm(L×W×H) Fan Noise ≤28 dB(A) Fan Power Consumption 1.2 W Fan Rated Current 0.1 A Fan Rated Voltage 12 VDC
| Bearing Type | Fluid Dynamic Bearing |
|---|---|
| Fan Air Pressure | 1.62 mmAq |
| Fan Airflow | 59.46 CFM |
| Fan Connector | 4-pin PWM |
| Fan Dimensions | 120×120×25 mm(L×W×H) |
| Fan Noise | ≤28 dB(A) |
| Fan Power Consumption | 1.2 W |
| Fan Rated Current | 0.1 A |
| Fan Rated Voltage | 12 VDC |
| Fan Speed | 500~1650 RPM±10% |
| Heatpipe | Ø6 mm×4 pcs |
| Heatsink Dimensions | 120×45×152 mm(L×W×H) |
| Net Weight | 802 g |
| P/N | R-AK400-BKNNMD-G-1 |
| Product Dimensions | 127×123×155 mm(L×W×H) |
| Bearing Type | Fluid Dynamic Bearing |
|---|---|
| Fan Air Pressure | 1.62 mmAq |
| Fan Airflow | 59.46 CFM |
| Fan Connector | 4-pin PWM |
| Fan Dimensions | 120×120×25 mm(L×W×H) |
| Fan Noise | ≤28 dB(A) |
| Fan Power Consumption | 1.2 W |
| Fan Rated Current | 0.1 A |
| Fan Rated Voltage | 12 VDC |
| Fan Speed | 500~1650 RPM±10% |
| Heatpipe | Ø6 mm×4 pcs |
| Heatsink Dimensions | 120×45×152 mm(L×W×H) |
| Net Weight | 802 g |
| P/N | R-AK400-BKNNMD-G-1 |
| Product Dimensions | 127×123×155 mm(L×W×H) |
