Feature Highlights: – Powered by the NVIDIA Blackwell architecture and DLSS 4- 8-Pin PCIe power connector- SFF-Ready compact Graphics Card- Metal Backplate- BladeLink Fans- All-new FireStorm Utility Specifications Category Specification GPU NVIDIA® GeForc
– Powered by the NVIDIA Blackwell architecture and DLSS 4
– 8-Pin PCIe power connector
– SFF-Ready compact Graphics Card
– Metal Backplate
– BladeLink Fans
– All-new FireStorm Utility
| Category | Specification |
|---|---|
| GPU | NVIDIA® GeForce RTX™ 5060 |
| CUDA Cores | 3840 |
| Video Memory | 8GB GDDR7 |
| Memory Bus | 128-bit |
| Engine Clock | 2497 MHz |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x8 |
| Display Outputs | 3 × DisplayPort 2.1b (UHBR20)1 × HDMI 2.1b (HDR, VRR, DSC) |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display |
| Recommended PSU | 550W |
| Power Consumption | 145W |
| Power Input | 1 × 8-pin |
| DirectX | Microsoft DirectX® 12 Ultimate |
| OpenGL | 4.6 |
| Cooling | Air Cooled |
| Slot Size | 2 |
| SLI Support | No |
| Supported OS | Windows 11 / 10 64-bit (v1809 or later) |
| Card Dimensions (L × W × H) | 220.5 × 120.25 × 41.6 mm (8.7″ × 4.7″ × 1.6″) |
| Accessories | User Manual |
| Warranty | 3 years + Additional 2 years after Registration |
– Powered by the NVIDIA Blackwell architecture and DLSS 4
– 8-Pin PCIe power connector
– SFF-Ready compact Graphics Card
– Metal Backplate
– BladeLink Fans
– All-new FireStorm Utility
| Category | Specification |
|---|---|
| GPU | NVIDIA® GeForce RTX™ 5060 |
| CUDA Cores | 3840 |
| Video Memory | 8GB GDDR7 |
| Memory Bus | 128-bit |
| Engine Clock | 2497 MHz |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x8 |
| Display Outputs | 3 × DisplayPort 2.1b (UHBR20)1 × HDMI 2.1b (HDR, VRR, DSC) |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display |
| Recommended PSU | 550W |
| Power Consumption | 145W |
| Power Input | 1 × 8-pin |
| DirectX | Microsoft DirectX® 12 Ultimate |
| OpenGL | 4.6 |
| Cooling | Air Cooled |
| Slot Size | 2 |
| SLI Support | No |
| Supported OS | Windows 11 / 10 64-bit (v1809 or later) |
| Card Dimensions (L × W × H) | 220.5 × 120.25 × 41.6 mm (8.7″ × 4.7″ × 1.6″) |
| Accessories | User Manual |
| Warranty | 3 years + Additional 2 years after Registration |
