Overview Specifications Description Display Size (in.): 27 Viewable Area (in.): 27 Panel Type: IPS Technology Resolution: 3840 x 2160 Resolution Type: UHD (Ultra HD) Static Contrast Ratio: 1,000:1 (typ) Dynamic Contrast Ratio: 50M:1 High Dynamic Range: HD
| Description | |
| Display Size (in.): | 27 |
| Viewable Area (in.): | 27 |
| Panel Type: | IPS Technology |
| Resolution: | 3840 x 2160 |
| Resolution Type: | UHD (Ultra HD) |
| Static Contrast Ratio: | 1,000:1 (typ) |
| Dynamic Contrast Ratio: | 50M:1 |
| High Dynamic Range: | HDR10 |
| Light Source: | LED |
| Brightness: | 250 cd/m² (typ) |
| Colors: | 1.07B |
| Color Space Support: | 10 bit (8 bit + FRC) |
| Aspect Ratio: | 16:09 |
| Response Time (GTG w/OD): | 3.8ms |
| Viewing Angles: | 178º horizontal, 178º vertical |
| Backlight Life (Hours): | 30000 Hrs (Min) |
| Curvature: | Flat |
| Refresh Rate (Hz): | 60 |
| Low Blue Light: | Software solution |
| Flicker-Free: | Yes |
| Color Gamut: | NTSC: 72% size (Typ) sRGB: 104% size (Typ) |
| Pixel Size: | 0.155 mm (H) x 0.155 mm (V) |
| Surface Treatment: | Anti-Glare, Hard Coating (3H) |
| COMPATIBILITY | |
| PC Resolution (max): | 3840×2160 |
| Mac® Resolution (max): | 3840×2160 |
| PC Operating System: | Windows 10/11 certified; macOS tested |
| Mac® Resolution (min): | 3840×2160 |
| CONNECTOR | |
| USB 3.2 Type A Down Stream: | 2 |
| USB 3.2 Type B Up Stream: | 1 |
| USB 3.2 Type C DisplayPort Alt mode only : | 1 (65W power charger) |
| 3.5mm Audio Out: | 1 |
| HDMI 2.0 (with HDCP 2.2): | 2 |
| DisplayPort: | 1 |
| Power in: | 3-pin Socket (IEC C14 / CEE22) |
| AUDIO | |
| Internal Speakers: | 2.5Watts x2 |
| POWER | |
| Eco Mode (Conserve): | 23W |
| Eco Mode (optimized): | 30W |
| Consumption (typical): | 38W |
| Consumption (max): | 45W |
| Voltage: | AC 100-240V |
| Stand-by: | 0.5W |
| Power Supply: | Internal Power Supply |
| ADDITIONAL HARDWARE | |
| Kensington Lock Slot: | 1 |
| Cable Organization: | Yes |
| CONTROLS | |
| Physical Controls: | Key 1 (favorite), Key 2, Key 3, Key 4, Key 5 (power) |
| On Screen Display: | Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu |
| OPERATING CONDITIONS | |
| Temperature: | 32°F to 104°F (0°C to 40°C) |
| Humidity (non-condensing): | 20% to 90% |
| WALL MOUNT | |
| VESA Compatible: | 100 x 100 mm |
| INPUT SIGNAL | |
| Frequency Horizontal: | HDMI (v2.0): 15 ~ 240KHz, DisplayPort (v1.4): 31 ~ 160KHz, Type C: 31 ~ 160KHz |
| Frequency Vertical: | HDMI (v2.0): 29 ~ 60Hz, DisplayPort (v1.4): 48 ~ 60Hz, Type C: 48 ~ 60Hz |
| VIDEO INPUT | |
| Digital Sync: | TMDS – HDMI (v2.0), PCI-E – DisplayPort (v1.4), Micro-Packet – Type C |
| ERGONOMICS | |
| Height Adjust (mm): | 150 |
| Swivel: | 90º |
| Tilt (Forward/Back): | -3.5º / 20º |
| Pivot (Right/Left): | 90º / 90º |
| WEIGHT (IMPERIAL) | |
| Net (lbs): | 14.3 |
| Net Without Stand (lbs): | 9.7 |
| Gross (lbs): | 17.9 |
| WEIGHT (METRIC) | |
| Net (kg): | 6.5 |
| Net Without Stand (kg): | 4.4 |
| Gross (kg): | 8.1 |
| DIMENSIONS (IMPERIAL) (WxHxD) | |
| Packaging (in.): | 30.1 x 17.8 x 5 |
| Physical (in.): | 24.2 x 15.51~21.43 x 8.4 |
| Physical Without Stand (in.): | 24.2 x 14.4 x 2 |
| DIMENSIONS (METRIC) (WxHxD) | |
| Packaging (mm): | 764 x 452 x 126 |
| Physical (mm): | 614 x 394~544.2 x 214 |
| Physical Without Stand (mm): | 614 x 366 x 51 |
| GENERAL | |
| Regulations: | RoHS, WEEE, BIS |
| PACKAGE CONTENTS: | VX2762U-4K x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v2.0; Male-Male) x1, USB Type-C Cable (Male-Male) x1, USB A/B Cable (v3.2; Male-Male) x1, Quick Start Guide x1 |
| Recycle/Disposal: | Please dispose of in accordance with local, state or federal laws. |
| Warranty: | 3 Years |
| Description | |
| Display Size (in.): | 27 |
| Viewable Area (in.): | 27 |
| Panel Type: | IPS Technology |
| Resolution: | 3840 x 2160 |
| Resolution Type: | UHD (Ultra HD) |
| Static Contrast Ratio: | 1,000:1 (typ) |
| Dynamic Contrast Ratio: | 50M:1 |
| High Dynamic Range: | HDR10 |
| Light Source: | LED |
| Brightness: | 250 cd/m² (typ) |
| Colors: | 1.07B |
| Color Space Support: | 10 bit (8 bit + FRC) |
| Aspect Ratio: | 16:09 |
| Response Time (GTG w/OD): | 3.8ms |
| Viewing Angles: | 178º horizontal, 178º vertical |
| Backlight Life (Hours): | 30000 Hrs (Min) |
| Curvature: | Flat |
| Refresh Rate (Hz): | 60 |
| Low Blue Light: | Software solution |
| Flicker-Free: | Yes |
| Color Gamut: | NTSC: 72% size (Typ) sRGB: 104% size (Typ) |
| Pixel Size: | 0.155 mm (H) x 0.155 mm (V) |
| Surface Treatment: | Anti-Glare, Hard Coating (3H) |
| COMPATIBILITY | |
| PC Resolution (max): | 3840×2160 |
| Mac® Resolution (max): | 3840×2160 |
| PC Operating System: | Windows 10/11 certified; macOS tested |
| Mac® Resolution (min): | 3840×2160 |
| CONNECTOR | |
| USB 3.2 Type A Down Stream: | 2 |
| USB 3.2 Type B Up Stream: | 1 |
| USB 3.2 Type C DisplayPort Alt mode only : | 1 (65W power charger) |
| 3.5mm Audio Out: | 1 |
| HDMI 2.0 (with HDCP 2.2): | 2 |
| DisplayPort: | 1 |
| Power in: | 3-pin Socket (IEC C14 / CEE22) |
| AUDIO | |
| Internal Speakers: | 2.5Watts x2 |
| POWER | |
| Eco Mode (Conserve): | 23W |
| Eco Mode (optimized): | 30W |
| Consumption (typical): | 38W |
| Consumption (max): | 45W |
| Voltage: | AC 100-240V |
| Stand-by: | 0.5W |
| Power Supply: | Internal Power Supply |
| ADDITIONAL HARDWARE | |
| Kensington Lock Slot: | 1 |
| Cable Organization: | Yes |
| CONTROLS | |
| Physical Controls: | Key 1 (favorite), Key 2, Key 3, Key 4, Key 5 (power) |
| On Screen Display: | Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu |
| OPERATING CONDITIONS | |
| Temperature: | 32°F to 104°F (0°C to 40°C) |
| Humidity (non-condensing): | 20% to 90% |
| WALL MOUNT | |
| VESA Compatible: | 100 x 100 mm |
| INPUT SIGNAL | |
| Frequency Horizontal: | HDMI (v2.0): 15 ~ 240KHz, DisplayPort (v1.4): 31 ~ 160KHz, Type C: 31 ~ 160KHz |
| Frequency Vertical: | HDMI (v2.0): 29 ~ 60Hz, DisplayPort (v1.4): 48 ~ 60Hz, Type C: 48 ~ 60Hz |
| VIDEO INPUT | |
| Digital Sync: | TMDS – HDMI (v2.0), PCI-E – DisplayPort (v1.4), Micro-Packet – Type C |
| ERGONOMICS | |
| Height Adjust (mm): | 150 |
| Swivel: | 90º |
| Tilt (Forward/Back): | -3.5º / 20º |
| Pivot (Right/Left): | 90º / 90º |
| WEIGHT (IMPERIAL) | |
| Net (lbs): | 14.3 |
| Net Without Stand (lbs): | 9.7 |
| Gross (lbs): | 17.9 |
| WEIGHT (METRIC) | |
| Net (kg): | 6.5 |
| Net Without Stand (kg): | 4.4 |
| Gross (kg): | 8.1 |
| DIMENSIONS (IMPERIAL) (WxHxD) | |
| Packaging (in.): | 30.1 x 17.8 x 5 |
| Physical (in.): | 24.2 x 15.51~21.43 x 8.4 |
| Physical Without Stand (in.): | 24.2 x 14.4 x 2 |
| DIMENSIONS (METRIC) (WxHxD) | |
| Packaging (mm): | 764 x 452 x 126 |
| Physical (mm): | 614 x 394~544.2 x 214 |
| Physical Without Stand (mm): | 614 x 366 x 51 |
| GENERAL | |
| Regulations: | RoHS, WEEE, BIS |
| PACKAGE CONTENTS: | VX2762U-4K x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v2.0; Male-Male) x1, USB Type-C Cable (Male-Male) x1, USB A/B Cable (v3.2; Male-Male) x1, Quick Start Guide x1 |
| Recycle/Disposal: | Please dispose of in accordance with local, state or federal laws. |
| Warranty: | 3 Years |
