Specifications: Category Details Print Method Serial Impact Dot Matrix Number Of Pins In Head 9 Pins Print Direction Bi-Directional Control Code Esc / P, Ibm Proprinter Print Width 80 Column Print Head Life 200 Plus Million Characters Print Speed (High Sp
| Category | Details |
|---|---|
| Print Method | Serial Impact Dot Matrix |
| Number Of Pins In Head | 9 Pins |
| Print Direction | Bi-Directional |
| Control Code | Esc / P, Ibm Proprinter |
| Print Width | 80 Column |
| Print Head Life | 200 Plus Million Characters |
| Print Speed (High Speed Draft) | 10 / 12 / 15 Cpi 350/360/400 Cps |
| Print Speed (Draft) | 10 / 12 / 15 Cpi 270 / 320 / 375 Cps |
| Print Speed (Nlq) | 10 / 12 / 15 65 /75 /75 Cps |
| Character Sets (Resident Printer Font) | Draft, Near Letter Quality |
| Resident Barcode Fonts | Code 3 Of 9 |
| Printable Columns (Pitch) | 10 / 12 / 15 / 17 / 20 Cpi |
| Printable Columns (Width) | 80 / 96 / 120 / 137 / 160 Cpl |
| Paper Handling (Paper Path) | Tractor / Manual (Top, Rear, Bottom), Continuous Tractor, Convertible Push And Pull |
| Paper Handling (Cut Sheet) | 3.5 – 10″ |
| Paper Handling (Paper Thickness) | 0.3 Mm |
| Paper Handling (Continuous Paper) | 3.5 – 10″ |
| Paper Handling (Roll Paper) | Yes |
| Paper Feeding (Standard) | Friction, Push Tractor |
| Copies | 1+3 With Carbon |
| Line Spacing | 4.23Mm (1/6″) Or Programmable In Increments Of 0.118Mm (1/216″) |
| Input Data Buffer | 100 Kb |
| Interface | Bi-Directional Parallel (Ieee-1284), Usb 2.0 Full-Speed, Serial (Optional) |
| Ribbon Cartridge | Patented Tvs-E Ribbon Cassette With User Replaceable Ink Bank |
| Reliability (Mtbf) | 15,000 Poh |
| Acoustics | 55 Db (A) In Iso 7779 Sonic Pattern |
| Emulation | Epson Esc/P, Ibm Proprinter |
| Control Panel | 4 Switches And 5 Leds |
| Environmental Conditions (Operating) | Temperature: (+5°C To +45°C), Humidity: 10% To 80% |
| Electrical Specification | Rated Voltage: 90V – 270V Ac, Rated Frequency: 47 – 63 Hz, Power Consumption (Operating): 34W, Self Test: 12W |
| Printer Driver / Utility | Operating System: Windows 9X, Nt 4.0, Me, 2000, 2003, Xp, Vista, Windows 7, Linux |
| Electronic Guide | Html Based |
| Dimensions (W X D X H) | 433 X 379 X 147 Mm |
| Weight | 5.7 Kg |
| Warranty | 1 Year |
