Specifications P/N CA-1Q4-00M1WN-00 SERIES / MODEL AH Series / AH T600 Warranty 1 Year CASE TYPE Full Tower DIMENSION (H X W X D) 628.3 x 337 x 763 mm (27.74 x 13.3 x 30 inch) NET WEIGHT 20.64 kg / 45.5 lb SIDE PANEL 5mm Tempered Glass x 2 COLOR Exterior
Specifications
| P/N | CA-1Q4-00M1WN-00 |
| SERIES / MODEL | AH Series / AH T600 |
| Warranty | 1 Year |
| CASE TYPE | Full Tower |
| DIMENSION (H X W X D) | 628.3 x 337 x 763 mm |
| (27.74 x 13.3 x 30 inch) | |
| NET WEIGHT | 20.64 kg / 45.5 lb |
| SIDE PANEL | 5mm Tempered Glass x 2 |
| COLOR | Exterior & Interior : Black |
| MATERIAL | SPCC |
| DRIVE BAYS | |
| -ACCESSIBLE | 2 x 3.5″ or 3 x 2.5″ |
| -HIDDEN | – |
| EXPANSION SLOTS | 8 |
| MOTHERBOARDS | 6.7î x 6.7î (Mini ITX), 9.6î x 9.6î (Micro ATX), |
| 12î x 9.6î (ATX), 12î x 10.5î (E-ATX) | |
| I/O PORT | 1 x USB 3.1 (Gen 2) Type C, USB 3.0 x 2, USB 2.0 x 1, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Front: |
| 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm | |
| 3 x 140mm or 2 x 140mm or 1 x 140mm | |
| Top: | |
| 3 x 120mm or 2 x 120mm or 1 x 120mm | |
| 2 x 140mm or 1 x 140mm | |
| Right: | |
| 3 x 120mm or 2 x 120mm or 1 x 120mm | |
| 2 x 140mm or 1 x 140mm | |
| RADIATOR SUPPORT | Front: |
| 1 x 480mm or 1 x 360mm or 1 x 240mm or 1 x 120mm | |
| 1 x 420mm or 1 x 280mm or 1 x 140mm | |
| Top: | |
| 1 x 360mm or 1 x 240mm or 1 x 120mm | |
| 1 x 280mm or 1 x 140mm | |
| Right: | |
| 1 x 360mm or 1 x 240mm or 1 x 120mm | |
| 1 x 280mm or 1 x 140mm | |
| CLEARANCE | CPU cooler height limitation: 195mm |
| VGA length limitation: 300mm(With Water Pump) | |
| 440mm(Without Water Pump) | |
| PSU length limitation: 200mm |
Specifications
| P/N | CA-1Q4-00M1WN-00 |
| SERIES / MODEL | AH Series / AH T600 |
| Warranty | 1 Year |
| CASE TYPE | Full Tower |
| DIMENSION (H X W X D) | 628.3 x 337 x 763 mm |
| (27.74 x 13.3 x 30 inch) | |
| NET WEIGHT | 20.64 kg / 45.5 lb |
| SIDE PANEL | 5mm Tempered Glass x 2 |
| COLOR | Exterior & Interior : Black |
| MATERIAL | SPCC |
| DRIVE BAYS | |
| -ACCESSIBLE | 2 x 3.5″ or 3 x 2.5″ |
| -HIDDEN | – |
| EXPANSION SLOTS | 8 |
| MOTHERBOARDS | 6.7î x 6.7î (Mini ITX), 9.6î x 9.6î (Micro ATX), |
| 12î x 9.6î (ATX), 12î x 10.5î (E-ATX) | |
| I/O PORT | 1 x USB 3.1 (Gen 2) Type C, USB 3.0 x 2, USB 2.0 x 1, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Front: |
| 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm | |
| 3 x 140mm or 2 x 140mm or 1 x 140mm | |
| Top: | |
| 3 x 120mm or 2 x 120mm or 1 x 120mm | |
| 2 x 140mm or 1 x 140mm | |
| Right: | |
| 3 x 120mm or 2 x 120mm or 1 x 120mm | |
| 2 x 140mm or 1 x 140mm | |
| RADIATOR SUPPORT | Front: |
| 1 x 480mm or 1 x 360mm or 1 x 240mm or 1 x 120mm | |
| 1 x 420mm or 1 x 280mm or 1 x 140mm | |
| Top: | |
| 1 x 360mm or 1 x 240mm or 1 x 120mm | |
| 1 x 280mm or 1 x 140mm | |
| Right: | |
| 1 x 360mm or 1 x 240mm or 1 x 120mm | |
| 1 x 280mm or 1 x 140mm | |
| CLEARANCE | CPU cooler height limitation: 195mm |
| VGA length limitation: 300mm(With Water Pump) | |
| 440mm(Without Water Pump) | |
| PSU length limitation: 200mm |
