Specifications P/N Ps-Spd-0550Nnfabx-1 Watts 550W Rgb Fan No Form Factor Atx Model Spd-550Ah2Nkb Type Atx 12V V2.3 And Eps V2.92 Max. Output Capacity 550W Color Black Dimension ( W / H / D ) 150Mm(W) X 86Mm(H) X 140Mm(D) Pfc (Power Factor Correction) Acti
| P/N | Ps-Spd-0550Nnfabx-1 |
| Watts | 550W |
| Rgb Fan | No |
| Form Factor | Atx |
| Model | Spd-550Ah2Nkb |
| Type | Atx 12V V2.3 And Eps V2.92 |
| Max. Output Capacity | 550W |
| Color | Black |
| Dimension ( W / H / D ) | 150Mm(W) X 86Mm(H) X 140Mm(D) |
| Pfc (Power Factor Correction) | Active Pfc |
| Power Good Signal | 100-500 Msec |
| Hold Up Time | ≫ 16Msec At 70% Of Full Load |
| Input Current | 10A Max. |
| Input Frequency Range | 50Hz – 60Hz |
| Input Voltage | 100V – 240V |
| Operating Temperature | 5C To + 40C |
| Operating Humidity | 20% To 85%, Non-Condensing |
| Storage Temperature | -40C To + 55C |
| Storage Humidity | 10% To 95%, Non-Condensing |
| Cooling System | 12Cm Hydraulic Bearing Fan |
| Efficiency | Meet 80 Plus Bronze At 115Vac Input. |
| Mtbf | 100,000 Hrs Minimum |
| Safety Approval | Ce/Cb/Tuv/ Ul/ Fcc/ Bsmi |
| Pci-E 6+2Pin | 2 |
| Warranty | 5 Years |
*Note: The Actual Colors May Be Different From The Color Displayed Here. Features, Price And Specifications Are Subject To Change Without Notice.
| P/N | Ps-Spd-0550Nnfabx-1 |
| Watts | 550W |
| Rgb Fan | No |
| Form Factor | Atx |
| Model | Spd-550Ah2Nkb |
| Type | Atx 12V V2.3 And Eps V2.92 |
| Max. Output Capacity | 550W |
| Color | Black |
| Dimension ( W / H / D ) | 150Mm(W) X 86Mm(H) X 140Mm(D) |
| Pfc (Power Factor Correction) | Active Pfc |
| Power Good Signal | 100-500 Msec |
| Hold Up Time | ≫ 16Msec At 70% Of Full Load |
| Input Current | 10A Max. |
| Input Frequency Range | 50Hz – 60Hz |
| Input Voltage | 100V – 240V |
| Operating Temperature | 5C To + 40C |
| Operating Humidity | 20% To 85%, Non-Condensing |
| Storage Temperature | -40C To + 55C |
| Storage Humidity | 10% To 95%, Non-Condensing |
| Cooling System | 12Cm Hydraulic Bearing Fan |
| Efficiency | Meet 80 Plus Bronze At 115Vac Input. |
| Mtbf | 100,000 Hrs Minimum |
| Safety Approval | Ce/Cb/Tuv/ Ul/ Fcc/ Bsmi |
| Pci-E 6+2Pin | 2 |
| Warranty | 5 Years |
*Note: The Actual Colors May Be Different From The Color Displayed Here. Features, Price And Specifications Are Subject To Change Without Notice.
