Specifications Architecture NVIDIA Ampere Architecture Process Size 8nm Transistors 28.3 Billion Die Size 628.4 mm CUDA Cores 10752 Tensor Cores 336 RT Cores 84 Single Precision Performance 38.7 TFLOPS RT Core Performance 75.6 TFLOPS Tensor Performance 30
| Architecture | NVIDIA Ampere Architecture |
| Process Size | 8nm |
| Transistors | 28.3 Billion |
| Die Size | 628.4 mm |
| CUDA Cores | 10752 |
| Tensor Cores | 336 |
| RT Cores | 84 |
| Single Precision Performance | 38.7 TFLOPS |
| RT Core Performance | 75.6 TFLOPS |
| Tensor Performance | 309.7 TFLOPS |
| GPU Memory | 48 GB GDDR6 with ECC |
| Memory Interface | 384-bit |
| Memory Bandwidth | 768 GB/sec |
| Display Connectors | 4x DisplayPort 1.4a |
| NVENC | NVDEC | 1x | 2x (+ AV1 decode) |
| System Interface | PCI Express 4.0 x16 |
| Form Factor | 4.4″ H x 10.5″ L Dual Slot |
| Thermal Solution | Active Fansink |
| Maximum Power Consumption | 300 W NVIDIA Quadro and RTX Power Guidelines |
| Power Connector | 1x 8-pin CPU |
| Max Digital Resolution | 7680 x 4320 x36 bpp at 60 Hz NVIDIA Quadro and RTX Display Resolution Support |
| vGPU Software Support | NVIDIA GRID, NVIDIA Virtual Data Center Workstation, NVIDIA Virtual Compute Server |
| vGPU Profiles Supported | 1 GB, 2 GB, 3 GB, 4 GB, 6 GB, 8 GB, 12 GB, 16 GB, 24 GB, 48 GB |
| NVIDIA 3D Vision and 3D Vision Pro | Support via 3-pin mini DIN |
| Frame Lock | Compatible with NVIDIA Quadro Sync II |
| NVLink | 2-way low profile (2-slot and 3-slot bridges) connects 2x NVIDIA RTX A6000 |
| NVLink Interconnect | 112.5 GB/sec bidirectional |
| Warranty | 3 Years |
| Architecture | NVIDIA Ampere Architecture |
| Process Size | 8nm |
| Transistors | 28.3 Billion |
| Die Size | 628.4 mm |
| CUDA Cores | 10752 |
| Tensor Cores | 336 |
| RT Cores | 84 |
| Single Precision Performance | 38.7 TFLOPS |
| RT Core Performance | 75.6 TFLOPS |
| Tensor Performance | 309.7 TFLOPS |
| GPU Memory | 48 GB GDDR6 with ECC |
| Memory Interface | 384-bit |
| Memory Bandwidth | 768 GB/sec |
| Display Connectors | 4x DisplayPort 1.4a |
| NVENC | NVDEC | 1x | 2x (+ AV1 decode) |
| System Interface | PCI Express 4.0 x16 |
| Form Factor | 4.4″ H x 10.5″ L Dual Slot |
| Thermal Solution | Active Fansink |
| Maximum Power Consumption | 300 W NVIDIA Quadro and RTX Power Guidelines |
| Power Connector | 1x 8-pin CPU |
| Max Digital Resolution | 7680 x 4320 x36 bpp at 60 Hz NVIDIA Quadro and RTX Display Resolution Support |
| vGPU Software Support | NVIDIA GRID, NVIDIA Virtual Data Center Workstation, NVIDIA Virtual Compute Server |
| vGPU Profiles Supported | 1 GB, 2 GB, 3 GB, 4 GB, 6 GB, 8 GB, 12 GB, 16 GB, 24 GB, 48 GB |
| NVIDIA 3D Vision and 3D Vision Pro | Support via 3-pin mini DIN |
| Frame Lock | Compatible with NVIDIA Quadro Sync II |
| NVLink | 2-way low profile (2-slot and 3-slot bridges) connects 2x NVIDIA RTX A6000 |
| NVLink Interconnect | 112.5 GB/sec bidirectional |
| Warranty | 3 Years |
