Nzxt
In Stock
₹12,200
Tech Specs: Category Specification Output Connectors 24-Pin Atx Power Cable 1 4+4-Pin Cpu Power Cable 1 8-Pin Cpu Power Cable 1 6+2-Pin Pcie Power Cable 3 16-Pin (12+4) 12V-2X6 Pcie Cable 1 Sata Cable 12 Peripherals Cable 4 Cable Specs 24-Pin Atx Power Ca
In Stock
In Stock
Additional information
Tech Specs:
| Category | Specification |
|---|---|
| Output Connectors | |
| 24-Pin Atx Power Cable | 1 |
| 4+4-Pin Cpu Power Cable | 1 |
| 8-Pin Cpu Power Cable | 1 |
| 6+2-Pin Pcie Power Cable | 3 |
| 16-Pin (12+4) 12V-2X6 Pcie Cable | 1 |
| Sata Cable | 12 |
| Peripherals Cable | 4 |
| Cable Specs | |
| 24-Pin Atx Power Cable | 600Mm With Nylon Sleeving |
| 4+4-Pin Cpu Power Cable | 700Mm With Nylon Sleeving |
| 8-Pin Cpu Power Cable | 700Mm With Nylon Sleeving |
| 6+2-Pin Pcie Power Cable | 650Mm With Nylon Sleeving |
| 16-Pin (12+4) 12V-2X6 Pcie Cable | 650Mm With Nylon Sleeving |
| Sata Cable | 500 + 150Mm |
| Peripherals Cable | 500 + 150Mm |
| Ac Input Rating | |
| 100 – 240Vac | 10A-5A 50Hz-60Hz |
| 200 – 240Vac | – |
| Dc Output Rating | |
| 3.3V / +5V | 22A (120W) |
| 12V | 70.83A (850W) |
| 5Vsb | 3A (15W) |
| Total Power Output | 850W |
| Energy Efficiency | |
| Rating | 80 Plus Gold |
| 10% Loading Efficiency | 85.8% @115Vac |
| 20% Loading Efficiency | 89.5% @115Vac |
| 50% Loading Efficiency | 91.7% @115Vac |
| 100% Loading Efficiency | 89.2% @115Vac |
| Electrical Features | |
| Power Factor Correction | Active @0.99 |
| Protections | Ovp (Overvoltage Protection), Uvp (Undervoltage Protection), Scp (Short Circuit Protection), Otp (Over Temperature Protection), Opp (Overpower Protection), Ocp (Overcurrent Protection) |
| Fan Specs | |
| Dimensions | 135 X 135 X 25 Mm |
| Speed | 2300 ± 10% Rpm |
| Airflow | 93.02 Cfm (Min.) |
| Noise Level | 44.5 Dba Max |
| Bearing Type | Fluid Dynamic Bearing (Fdb) |
| Operation | |
| Mtbf | 100,000 Hours |
| Temperature Range | 0 – 50 °C |
| Dimensions | |
| Width | 150 Mm |
| Height | 86 Mm |
| Depth | 160 Mm |
| General | |
| Material(S) | Steel, Pcb, And Plastic |
| Compliance Standard | Atx12V V3.1 / Eps12V V2.92 |
| Regulations &Amp; Certifications | Fcc, Canada, Ce, Cb (Iec 62368-1), Ukca, Ccc, Bsmi, Bis, Rcm, Uae, Tuv, Ctuvus, Kc, Cp65 |
| Warranty | 10 Years |
| Model Numbers | |
| Black | Pa-8G2Bb-Cn / Pa-8G2Bb-Uk / Pa-8G2Bb-Us / Pa-8G2Bb-Eu / Pa-8G2Bb-Jp / Pa-8G2Bb-Au |
| White | Pa-8G2Bw-Cn / Pa-8G2Bw-Uk / Pa-8G2Bw-Us / Pa-8G2Bw-Eu / Pa-8G2Bw-Jp / Pa-8G2Bw-Au |
| Ean (Black) | |
| Cn | 5056547204765 |
| Uk | 5056547204772 |
| Us | 5056547204789 |
| Eu | 5056547204796 |
| Jp | 5056547204802 |
| Au | 5056547204819 |
| Ean (White) | |
| Cn | 5056547206387 |
| Uk | 5056547206394 |
| Us | 5056547206400 |
| Eu | 5056547206417 |
| Jp | 5056547206424 |
| Au | 5056547206431 |
| Upc (Black) | |
| Cn | 810074844833 |
| Uk | 810074844840 |
| Us | 810074844857 |
| Eu | 810074844864 |
| Jp | 810074844871 |
| Au | 810074844888 |
| Upc (White) | |
| Cn | 810074846448 |
| Uk | 810074846455 |
| Us | 810074846462 |
| Eu | 810074846479 |
| Jp | 810074846486 |
| Au | 810074846493 |
