Platform Intel Socket Lga1851 Cpu Type Core Ultra Chipset Z890 Memory Speed Up To 8800 Max Memory Support 256 Gb Supported Memory Type Ddr5 Channel Supported Dual Channel Memory Feature Supports Intel® Por Speed And Jedec Speedsupports Memory Overclockin
| Platform | Intel |
| Socket | Lga1851 |
| Cpu Type | Core Ultra |
| Chipset | Z890 |
| Memory Speed | Up To 8800 |
| Max Memory Support | 256 Gb |
| Supported Memory Type | Ddr5 |
| Channel Supported | Dual Channel |
| Memory Feature | Supports Intel® Por Speed And Jedec Speed Supports Memory Overclocking And Intel® Xmp 3.0 Supports Dual-Controller Dual-Channel Mode Supports Non-Ecc, Un-Buffered Memory Supports Cudimm • The Dimm Slots On This Motherboard Have Double-Sided Latches. • Memory Compatibility And Supported Speeds Can Vary Depending On The Cpu And Memory Configuration. For Detailed Information, Please Refer To The Memory Compatibility List Available On The Product’S Support Page Or Visit Brand Site. |
| Graphics Port | 1X Hdmi,1X Displayport,1X Type-C Displayport |
| Expansion Slots | 4X Pci-E X16 Slot Pci_E1 Gen Pcie 5.0 Supports Up To X16 (From Cpu) Pci_E2 Gen Pcie 3.0 Supports Up To X1 (From Chipset) Pci_E3 Gen Pcie 4.0 Supports Up To X4 (From Chipset) Pci_E4 Gen Pcie 4.0 Supports Up To X4 (From Cpu) |
| Wireless Networking | Wifi 7,Bluetooth 5.4 |
| Back Panel I/O Ports | Displayport Usb 5Gbps Type-A 2.5G Lan Wi-Fi / Bluetooth Audio Connectors Hdmi™ Thunderbolt™ 4 40Gbps (Type-C) Usb 20Gbps Type-C Usb 5Gbps Type-A |
| Internal I/O Connector | 1X Thunderbolt5 Card Connector(Jtbt5, Support Rtd3) 1X Power Connector(Atx_Pwr) 2X Power Connector(Cpu_Pwr) 1X Power Connector(Pcie_Pwr 8Pin) 1X Cpu Fan 1X Combo Fan (Pump_Sys Fan) 4X System Fan 1X Ez Conn-Header (Jaf_1) 2X Front Panel (Jfp) 1X Chassis Intrusion (Jci) 1X Front Audio (Jaud) 1X Tuning Controller Connector(Jdash) 3X Addressable V2 Rgb Led Connector (Jargb_V2) 1X Rgb Led Connector(Jrgb) 1X Tpm Pin Header(Support Tpm 2.0) 4X Usb 2.0 Ports 2X Usb 5Gbps Type A Ports 1X Usb 20Gbps Type C Ports |
| Form Factor | Atx |
| Warranty | 3 Years |
| Platform | Intel |
| Socket | Lga1851 |
| Cpu Type | Core Ultra |
| Chipset | Z890 |
| Memory Speed | Up To 8800 |
| Max Memory Support | 256 Gb |
| Supported Memory Type | Ddr5 |
| Channel Supported | Dual Channel |
| Memory Feature | Supports Intel® Por Speed And Jedec Speed Supports Memory Overclocking And Intel® Xmp 3.0 Supports Dual-Controller Dual-Channel Mode Supports Non-Ecc, Un-Buffered Memory Supports Cudimm • The Dimm Slots On This Motherboard Have Double-Sided Latches. • Memory Compatibility And Supported Speeds Can Vary Depending On The Cpu And Memory Configuration. For Detailed Information, Please Refer To The Memory Compatibility List Available On The Product’S Support Page Or Visit Brand Site. |
| Graphics Port | 1X Hdmi,1X Displayport,1X Type-C Displayport |
| Expansion Slots | 4X Pci-E X16 Slot Pci_E1 Gen Pcie 5.0 Supports Up To X16 (From Cpu) Pci_E2 Gen Pcie 3.0 Supports Up To X1 (From Chipset) Pci_E3 Gen Pcie 4.0 Supports Up To X4 (From Chipset) Pci_E4 Gen Pcie 4.0 Supports Up To X4 (From Cpu) |
| Wireless Networking | Wifi 7,Bluetooth 5.4 |
| Back Panel I/O Ports | Displayport Usb 5Gbps Type-A 2.5G Lan Wi-Fi / Bluetooth Audio Connectors Hdmi™ Thunderbolt™ 4 40Gbps (Type-C) Usb 20Gbps Type-C Usb 5Gbps Type-A |
| Internal I/O Connector | 1X Thunderbolt5 Card Connector(Jtbt5, Support Rtd3) 1X Power Connector(Atx_Pwr) 2X Power Connector(Cpu_Pwr) 1X Power Connector(Pcie_Pwr 8Pin) 1X Cpu Fan 1X Combo Fan (Pump_Sys Fan) 4X System Fan 1X Ez Conn-Header (Jaf_1) 2X Front Panel (Jfp) 1X Chassis Intrusion (Jci) 1X Front Audio (Jaud) 1X Tuning Controller Connector(Jdash) 3X Addressable V2 Rgb Led Connector (Jargb_V2) 1X Rgb Led Connector(Jrgb) 1X Tpm Pin Header(Support Tpm 2.0) 4X Usb 2.0 Ports 2X Usb 5Gbps Type A Ports 1X Usb 20Gbps Type C Ports |
| Form Factor | Atx |
| Warranty | 3 Years |
