Features 300Mbps wireless transmission rate is ideal for basic work Two 5dBi antennas provides broad wireless coverage Intuitive webpage guides you through the setup process in minutes Specifications Wireless Wireless Standards IEEE 802.11n, IEEE 802.11g,
Features
Specifications
| Wireless | Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Frequency | 2.4 – 2.4835GHz | |
| Signal Rate | 11n: Up to 300Mbps (Dynamic) | |
| 11g: Up to 54Mbps (Dynamic) | ||
| 11b: Up to 11Mbps (Dynamic) | ||
| Reception Sensitivity | 270M: -70dBm@10% PER | |
| 130M: -74dBm@10% PER | ||
| 108M: -77dBm@10% PER | ||
| 54M: -76dBm@10% PER | ||
| 11M: -90dBm@8% PER | ||
| 6M: -92dBm@10% PER | ||
| 1M: -97dBm@8% PER | ||
| Transmission Power | <20dBm | |
| Wireless Security | WPA-PSK / WPA2-PSK | |
| Wireless Functions | WDS bridge | |
| Software | WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
| Management | Parental Control | |
| Access control | ||
| Local management | ||
| Remote management | ||
| DHCP | Server | |
| Port Forwarding | Virtual server, UPnP, DMZ | |
| Dynamic DNS | DynDNS?NO-IP | |
| Firewall Security | IP and MAC address binding | |
| Protocols | IPv4, IPv6 | |
| Guest Network | 2.4GHz guest network | |
| Hardware | Dimensions (W X D X H) | 114x94x26 mm |
| Interfaces | 2 10/100Mbps LAN ports | |
| 1 10/100Mbps WAN port | ||
| Button | RESET | |
| External Power Supply | 5VDC/0.6A | |
| Antenna Type | 2 x 5dBi fixed omni directional antennas | |
| Others | Certifications | CE, ROHS |
| Package Contents | 300Mbps Wireless N Router | |
| MW301R | ||
| Power adapter | ||
| Quick Installation Guide | ||
| Ethernet cable | ||
| Environment | Operating temperature: 0?C ~ 40?C (32?F ~ 104?F) | |
| Storage temperature: -40?C ~ 70?C (-40?F ~ 158?F) | ||
| Operating humidity: 10% ~ 90%, non-condensing | ||
| Storage humidity: 5% ~ 90%, non-condensing |
Features
Specifications
| Wireless | Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Frequency | 2.4 – 2.4835GHz | |
| Signal Rate | 11n: Up to 300Mbps (Dynamic) | |
| 11g: Up to 54Mbps (Dynamic) | ||
| 11b: Up to 11Mbps (Dynamic) | ||
| Reception Sensitivity | 270M: -70dBm@10% PER | |
| 130M: -74dBm@10% PER | ||
| 108M: -77dBm@10% PER | ||
| 54M: -76dBm@10% PER | ||
| 11M: -90dBm@8% PER | ||
| 6M: -92dBm@10% PER | ||
| 1M: -97dBm@8% PER | ||
| Transmission Power | <20dBm | |
| Wireless Security | WPA-PSK / WPA2-PSK | |
| Wireless Functions | WDS bridge | |
| Software | WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
| Management | Parental Control | |
| Access control | ||
| Local management | ||
| Remote management | ||
| DHCP | Server | |
| Port Forwarding | Virtual server, UPnP, DMZ | |
| Dynamic DNS | DynDNS?NO-IP | |
| Firewall Security | IP and MAC address binding | |
| Protocols | IPv4, IPv6 | |
| Guest Network | 2.4GHz guest network | |
| Hardware | Dimensions (W X D X H) | 114x94x26 mm |
| Interfaces | 2 10/100Mbps LAN ports | |
| 1 10/100Mbps WAN port | ||
| Button | RESET | |
| External Power Supply | 5VDC/0.6A | |
| Antenna Type | 2 x 5dBi fixed omni directional antennas | |
| Others | Certifications | CE, ROHS |
| Package Contents | 300Mbps Wireless N Router | |
| MW301R | ||
| Power adapter | ||
| Quick Installation Guide | ||
| Ethernet cable | ||
| Environment | Operating temperature: 0?C ~ 40?C (32?F ~ 104?F) | |
| Storage temperature: -40?C ~ 70?C (-40?F ~ 158?F) | ||
| Operating humidity: 10% ~ 90%, non-condensing | ||
| Storage humidity: 5% ~ 90%, non-condensing |
