PERFORMANCE: Processor Intel Core i7-13620H, 10C (6P + 4E) / 16T, P-core 2.4 / 4.9GHz, E-core 1.8 / 3.6GHz, 24MB Graphics Integrated Intel UHD Graphics Chipset Intel SoC Platform Memory 16GB Soldered LPDDR5x-5200 Memory Slots Memory soldered to systemboa
PERFORMANCE:
|
|
| Processor |
Intel Core i7-13620H, 10C (6P + 4E) / 16T, P-core 2.4 / 4.9GHz, E-core 1.8 / 3.6GHz, 24MB
|
| Graphics |
Integrated Intel UHD Graphics
|
| Chipset |
Intel SoC Platform
|
| Memory |
16GB Soldered LPDDR5x-5200
|
| Memory Slots |
Memory soldered to systemboard, no slots, dual-channel
|
| Max Memory |
16GB soldered memory, not upgradable
|
| Storage |
512GB SSD M.2 2242 PCIe 4.0×4 NVMe
|
| Storage Support |
One drive, up to 1TB M.2 2242 SSD
|
| Storage Slot |
One M.2 2242 PCIe 4.0 x4 slot
|
| Card Reader |
microSD Card Reader
|
| Audio Chip |
High Definition (HD) Audio, Realtek ALC3287 codec
|
| Speakers |
Stereo speakers, 2W x2, optimized with Dolby Audio
|
| Camera |
FHD 1080p with Privacy Shutter
|
| Microphone |
2x, Array
|
| Battery |
Integrated 57Wh
|
| Power Adapter |
65W USB-C (3-pin)
|
| DESIGN | |
| Display |
14″ WUXGA (1920×1200) OLED 400nits Glossy, 100% DCI-P3, 60Hz, TV Low Blue Light, Glass, Touch
|
| Touchscreen |
10-point Multi-touch
|
| Color Calibration |
None
|
| Keyboard |
Backlit, English
|
| Touchpad |
Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
|
| Case Color |
Luna Grey
|
| Surface Treatment |
Aluminium Stamping (Anodized with Sandblasting)
|
| Case Material |
Aluminium (Top), PC-ABS + 40% GF (Bottom)
|
| Pen |
Lenovo Digital Pen 2
|
| Dimensions (WxDxH) |
313 x 227 x 17.5 mm (12.32 x 8.94 x 0.69 inches)
|
| Weight |
Starting at 1.5 kg (3.31 lbs)
|
| SOFTWARE | |
| Operating System |
Windows 11 Home Single Language, English
|
| Bundled Software |
Office Home 2024
|
| CONNECTIVITY | |
| Ethernet |
No Onboard Ethernet
|
| WLAN + Bluetooth |
Wi-Fi 6, 802.11ax 2×2 + BT5.2
|
| WWAN |
Non-WWAN
|
| Standard Ports |
|
| Docking |
Various docking solutions are supported via USB-C. For more compatible docking solutions, please visit Docking for IdeaPad 5 2-in-1 14IRH9
|
| SECURITY & PRIVACY | |
| Security Chip |
Firmware TPM 2.0
|
| Fingerprint Reader |
Touch Style, on Palm Rest
|
| Other Security |
Camera privacy shutter
|
| SERVICE | |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
1Y Accidental Damage Protection Add On, 1Y Premium Care with Onsite upgrade from 1Y Depot/CCI
|
| ACCESSORIES | |
| Bundled Accessories |
None
|
| CERTIFICATIONS | |
| Green Certifications |
|
| Other Certifications |
Models with OLED panel: TUV Rheinland Low Blue Light (Hardware Solution)
|
| Mil-Spec Test |
MIL-STD-810H military test passed (21 test items)
|
