Processor Number |
I3-12100 |
Lithography |
Intel 7 |
Cpu Specifications |
|
Total |
Cores 4 |
Performance-Cores |
4 |
Efficient-Cores |
0 |
Total Threads |
8 |
Max Turbo Frequency |
4.30 Ghz |
Performance-Core Max Turbo Frequency |
4.30 Ghz |
Performance-Core Base Frequency |
3.30 Ghz |
Cache |
12 Mb Intel Smart Cache |
Total L2 Cache |
5 Mb |
Processor Base Power |
60 W |
Maximum Turbo Power |
89 W |
Supplemental Information |
|
Embedded Options Available |
Yes |
Memory Specifications |
|
Max Memory Size (Dependent On Memory Type) |
128 Gb |
Memory Types |
Up To Ddr5 4800 Mt/S |
|
Up To Ddr4 3200 Mt/S |
Max # Of Memory Channels |
2 |
Max Memory Bandwidth |
76.8 Gb/S |
Processor Graphics |
|
Processor Graphics |
Intel Uhd Graphics 730 |
Graphics Base Frequency |
300 Mhz |
Graphics Max Dynamic Frequency |
1.40 Ghz |
Graphics Output |
Edp 1.4B, Dp 1.4A, Hdmi 2.1 |
Execution Units |
24 |
Max Resolution (Hdmi) |
4096 X 2160 @ 60Hz |
Max Resolution (Dp) |
7680 X 4320 @ 60Hz |
Max Resolution (Edp – Integrated Flat Panel) |
5120 X 3200 @ 120Hz |
Directx* Support |
12 |
Opengl* Support |
4.5 |
Multi-Format Codec Engines |
1 |
Intel Quick Sync Video |
Yes |
Intel Clear Video Hd Technology |
Yes |
# Of Displays Supported Á |
4 |
Device Id |
0X4692 |
Opencl* Support |
2.1 |
Expansion Options |
|
Direct Media Interface (Dmi) Revision |
4.0 |
Max # Of Dmi Lanes |
8 |
Scalability |
1S Only |
Pci Express Revision |
5.0 And 4.0 |
Pci Express Configurations |
Up To 1X16+4, 2X8+4 |
Max # Of Pci Express Lanes |
20 |
Package Specifications |
|
Sockets Supported |
Fclga1700 |
Max Cpu Configuration |
1 |
Thermal Solution Specification |
Pcg 2020C |
Tjunction |
100∞C |
Package Size |
45.0 Mm X 37.5 Mm |
Advanced Technologies |
|
Intel Gaussian &Amp; Neural Accelerator |
3.0 |
Intel Thread Director |
No |
Intel Deep Learning Boost (Intel Dl Boost) |
Yes |
Intel Optane Memory Supported |
Yes |
Intel Speed Shift Technology |
Yes |
Intel Turbo Boost Max Technology 3.0 |
No |
Intel Turbo Boost Technology |
2.0 |
Intel Hyper-Threading Technology |
Yes |
Intel 64 |
Yes |
Instruction Set |
64-Bit |
Instruction Set Extensions |
Intel Sse4.1, Intel Sse4.2, Intel Avx2 |
Idle States |
Yes |
Enhanced Intel Speed Step Technology |
Yes |
Thermal Monitoring Technologies |
Yes |
Intel Volume Management Device (Vmd) |
Yes |
Security &Amp; Reliability |
|
Intel Threat Detection Technology (Tdt) |
Yes |
Intel Standard Manageability (Ism) |
Yes |
Intel Aes New Instructions |
Yes |
Secure Key |
Yes |
Intel Os Guard |
Yes |
Execute Disable Bit |
Yes |
Intel Boot Guard |
Yes |
Mode-Based Execute Control (Mbec) |
Yes |
Intel Control-Flow Enforcement Technology |
Yes |
Intel Virtualization Technology (Vt-X) |
Yes |
Intel Virtualization Technology For Directed I/O (Vt-D) |
Yes |
Intel Vt-X With Extended Page Tables (Ept) |
Yes |
