Specifications
| Essentials | |
| Product Collection | 12Th Generation Intel Coreô I7 Processors |
| Code Name | Products Formerly Alder Lake |
| Vertical Segment | Desktop |
| Processor Number | I7-12700F |
| Status | Launched |
| Launch Date | Q1’22 |
| Lithography | Intel 7 |
| Use Conditions | Pc/Client/Tablet |
| Recommended Customer Price | $314.00 – $324.00 |
| Cpu Specifications | |
| Total Cores | 12 |
| # Of Performance-Cores | 8 |
| # Of Efficient-Cores | 4 |
| Total Threads | 20 |
| Max Turbo Frequency | 4.90 Ghz |
| Intel Turbo Boost Max Technology 3.0 Frequency Á | 4.90 Ghz |
| Performance-Core Max Turbo Frequency | 4.80 Ghz |
| Efficient-Core Max Turbo Frequency | 3.60 Ghz |
| Performance-Core Base Frequency | 2.10 Ghz |
| Efficient-Core Base Frequency | 1.60 Ghz |
| Cache | 25 Mb Intel Smart Cache |
| Total L2 Cache | 12 Mb |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 180 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (Dependent On Memory Type) | 128 Gb |
| Memory Types | Up To Ddr5 4800 Mt/S Up To Ddr4 3200 Mt/S |
| Max # Of Memory Channels | 2 |
| Max Memory Bandwidth | 76.8 Gb/S |
| Expansion Options | |
| Direct Media Interface (Dmi) Revision | 4 |
| Max # Of Dmi Lanes | 8 |
| Scalability | 1S Only |
| Pci Express Revision | 5.0 And 4.0 |
| Pci Express Configurations Á | Up To 1X16+4 | 2X8+4 |
| Max # Of Pci Express Lanes | 20 |
| Package Specifications | |
| Sockets Supported | Fclga1700 |
| Max Cpu Configuration | 1 |
| Thermal Solution Specification | Pcg 2020C |
| Tjunction | 100∞C |
| Package Size | 45.0 Mm X 37.5 Mm |
| Advanced Technologies | |
| Intel Gaussian &Amp; Neural Accelerator | 3 |
| Intel Thread Director | Yes |
| Intel Deep Learning Boost (Intel Dl Boost) | Yes |
| Intel Optaneô Memory Supported Á | Yes |
| Intel Speed Shift Technology | Yes |
| Intel Turbo Boost Max Technology 3.0 Á | Yes |
| Intel Turbo Boost Technology Á | 2 |
| Intel Hyper-Threading Technology Á | Yes |
| Intel 64 Á | Yes |
| Instruction Set | 64-Bit |
| Instruction Set Extensions | Intel Sse4.1 | Intel Sse4.2 | Intel Avx2 |
| Idle States | Yes |
| Enhanced Intel Speedstep Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel Volume Management Device (Vmd) | Yes |
| Security &Amp; Reliability | |
| Intel Standard Manageability (Ism) Á | Yes |
| Intel Aes New Instructions | Yes |
| Secure Key | Yes |
| Intel Os Guard | Yes |
| Execute Disable Bit Á | Yes |
| Intel Boot Guard | Yes |
| Mode-Based Execute Control (Mbec) | Yes |
| Intel Control-Flow Enforcement Technology | Yes |
| Intel Virtualization Technology (Vt-X) Á | Yes |
| Intel Virtualization Technology For Directed I/O (Vt-D) Á | Yes |
| Intel Vt-X With Extended Page Tables (Ept) Á | Yes |
