Specifications Category Details Model Gp-Ud1000Gm Type Intel Form Factor Atx 12V V2.31 Pfc Active Pfc (>0.9 Typical) Input Voltage 100-240V Ac (Full Range) Input Current 15-6.5A Input Frequency 50-60 Hz Output Capacity 1000W Dimensions (L W H) 150 1
| Category | Details |
|---|---|
| Model | Gp-Ud1000Gm |
| Type | Intel Form Factor Atx 12V V2.31 |
| Pfc | Active Pfc (≫0.9 Typical) |
| Input Voltage | 100-240V Ac (Full Range) |
| Input Current | 15-6.5A |
| Input Frequency | 50-60 Hz |
| Output Capacity | 1000W |
| Dimensions (L W H) | 150 140 86 Mm |
| Fan Type | 120Mm Hydraulic Bearing (Hyb) Fan |
| 80 Plus Rating | Gold |
| Efficiency | 90% At Typical Load |
| Mtbf | ≫100,000 Hours |
| Protections | Ovp / Opp / Scp / Uvp / Ocp / Otp |
| Power Good Signal | 100 – 150 Ms |
| Hold Up Time | ≫16 Ms |
| Cable Type | Flat, All Black |
| Connectors | – 1 Atx/Mb 20+4 Pin (610Mm) – 2 Cpu/Eps 4+4 Pin (600Mm Each) – 6 Pci-E 6+2 Pin (600Mm + 150Mm 3) – 8 Sata (600Mm + 150Mm + 150Mm + 150Mm 2) – 3 4-Pin Peripheral + 1 4-Pin Floppy (500Mm + 120Mm + 120Mm + 150Mm) |
| Category | Details |
|---|---|
| Model | Gp-Ud1000Gm |
| Type | Intel Form Factor Atx 12V V2.31 |
| Pfc | Active Pfc (≫0.9 Typical) |
| Input Voltage | 100-240V Ac (Full Range) |
| Input Current | 15-6.5A |
| Input Frequency | 50-60 Hz |
| Output Capacity | 1000W |
| Dimensions (L W H) | 150 140 86 Mm |
| Fan Type | 120Mm Hydraulic Bearing (Hyb) Fan |
| 80 Plus Rating | Gold |
| Efficiency | 90% At Typical Load |
| Mtbf | ≫100,000 Hours |
| Protections | Ovp / Opp / Scp / Uvp / Ocp / Otp |
| Power Good Signal | 100 – 150 Ms |
| Hold Up Time | ≫16 Ms |
| Cable Type | Flat, All Black |
| Connectors | – 1 Atx/Mb 20+4 Pin (610Mm) – 2 Cpu/Eps 4+4 Pin (600Mm Each) – 6 Pci-E 6+2 Pin (600Mm + 150Mm 3) – 8 Sata (600Mm + 150Mm + 150Mm + 150Mm 2) – 3 4-Pin Peripheral + 1 4-Pin Floppy (500Mm + 120Mm + 120Mm + 150Mm) |
