| Specifications |
3.5″/2.5″ drive mounts |
2 |
| |
Dedicated 2.5″ drive mounts |
2 trays included, 4 positions total |
| |
Expansion slots |
7 |
| |
Front interface |
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, 2x USB 2.0, Audio I/O, Power button, Reset button |
| |
Total fan mounts |
7x 120 or 4x 140 mm and 2x 120 mm |
| |
Front fan |
3x 120 or 2x 140 mm, (1x Dynamic X2 GP-14 included) |
| |
Top fan |
2x 120 or 2x 140 mm |
| |
Rear fan |
1x 120 mm, (1x Dynamic X2 GP-12 included) |
| |
Bottom fan |
1x 120 mm (requires removal of HDD cage) |
| |
Dust filters |
Top, 2x front, full length bottom |
| |
Fixed velcro straps |
Yes |
| |
Cable routing grommets |
Yes |
| |
Captive thumbscrews |
HDD brackets, SSD brackets, PSU bracket |
| |
Left side panel |
Industrial sound-damped steel or Tempered Glass |
| |
Right side panel |
Industrial sound-damped steel |
| Compatibility |
Motherboard compatibility |
ATX / mATX / Mini-ITX |
| |
Power supply type |
ATX |
| |
PSU max length |
200 mm total (165 mm w/ HDD cage and front fan) |
| |
GPU max length |
341 mm (360 mm without front fan) |
| |
CPU cooler max height |
169 mm |
| |
Front radiator |
Up to 360/280 mm (max 145 mm width) |
| |
Top radiator |
Up to 240 mm |
| |
Rear radiator |
120 mm |
| |
Bottom radiator |
120 mm (requires removal of HDD cage) |
| |
Cable routing space |
17-28 mm |
| Dimensions |
Case dimensions (LxWxH) |
427 x 210 x 474 mm |
| |
Case dimensions w/o feet/protrusions/screws |
415 x 210 x 451 mm |
| |
Package dimensions (LxWxH) |
536 x 310 x 521 mm |
| |
Net weight |
Solid version: 8.61 kg, TG Version: 8.76 kg |
| |
Package weight |
Solid version: 10.87 kg, TG Version: 11.04 kg |
| |
Volume |
39.3 liters |
| Other |
Warranty |
2 Years |
| |
Package contents |
Define 7 Compact, Accessory box, User manual, Ventilated top panel |
| |
EAN |
Black Solid – 7340172702160, White Solid – 7340172702764, Black TG Dark Tint – 7340172702177, Black TG Light Tint – 7340172702184, White TG Clear Tint – 7340172702719 |
| |
UPC |
Black Solid – 843276102166, White Solid – 843276102760, Black TG Dark Tint – 843276102173, Black TG Light Tint – 843276102180, White TG Clear Tint – 843276102715 |
| |
JAN |
Black Solid – 4537694275712, White Solid – 4537694280839, Black TG Dark Tint – 4537694275729, Black TG Light Tint – 4537694275736 , White TG Clear Tint – 4537694280822 |
| |
Product code |
Black Solid – FD-C-DEF7C-01, White Solid – FD-C-DEF7C-05, Black TG Dark Tint – FD-C-DEF7C-02, Black TG Light Tint – FD-C-DEF7C-03, White TG Clear Tint – FD-C-DEF7C-04 |
