Model Number MB520-WGNN-S00 Exterior Color White Materials – Exterior Mesh, Steel, ABS Plastic, Tempered Glass Materials – Left Side Panel Tempered Glass Dimensions (L x W x H) 499 x 210 x 498mm (Incl. Protrusions), 430 x 210 x 479mm (Body Size) Motherbo
|
Model Number
|
MB520-WGNN-S00 |
|
Exterior Color
|
White |
|
Materials – Exterior
|
Mesh, Steel, ABS Plastic, Tempered Glass |
|
Materials – Left Side Panel
|
Tempered Glass |
|
Dimensions (L x W x H)
|
499 x 210 x 498mm (Incl. Protrusions), 430 x 210 x 479mm (Body Size) |
|
Motherboard Support
|
Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12″ x 10.7″ motherboards, may impact cable management feature) |
|
Expansion Slots
|
7 |
|
3.5″ Drive Bays
|
2 |
|
2.5″ Drive Bays
|
3 |
|
I/O Panel
|
1x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button |
|
Included Accessories
|
ARGB Fans Hub |
|
Pre-installed Fans – Front
|
3x CF120 ARGB |
|
Fan Support – Top
|
3x 120mm, 2x 140mm |
|
Fan Support – Front
|
3x 120mm, 2x 140mm |
|
Fan Support – Rear
|
1x 120mm |
|
Radiator Support – Top
|
120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm) |
|
Radiator Support – Front
|
120mm, 140mm, 240mm, 280mm, 360mm |
|
Radiator Support – Rear
|
120mm |
|
Clearance – CPU Cooler
|
165mm / 6.49″ |
|
Clearance – PSU
|
200mm, (Recommended up to 170mm) |
|
Clearance – GFX
|
410mm/16.1″ |
|
Dust Filters
|
Bottom, Front, Top |
|
Power Supply Support
|
ATX |
|
Warranty
|
2 Years |
|
Series
|
MasterBox Series |
|
Size
|
Mid Tower |
*Note: The actual colors may be different from the color displayed here. Features, Price and Specifications are subject to change without notice.
|
