Series MasterBox Series Size Mid Tower Color(s) Black Materials Steel, Plastic, Tempered Glass Dimensions (L x W x H) 496 x 217 x 469 mm Weight 6.59 kg Motherboard Support Mini ITX, Micro ATX, ATX, SSI CEB*, E-ATX*, (*up to 12″ x 10.7″ motherboards, may
|
Series
|
MasterBox Series |
|
Size
|
Mid Tower |
|
Color(s)
|
Black |
|
Materials
|
Steel, Plastic, Tempered Glass |
|
Dimensions (L x W x H)
|
496 x 217 x 469 mm |
|
Weight
|
6.59 kg |
|
Motherboard Support
|
Mini ITX, Micro ATX, ATX, SSI CEB*, E-ATX*, (*up to 12″ x 10.7″ motherboards, may impact cable management feature) |
|
Expansion Slots
|
7 |
|
5.25″ Drive Bays
|
N/A |
|
2.5″ / 3.5″ Drive Bays (Combo)
|
2 (Max.2) |
|
2.5″ Drive Bays
|
4 (Max.6) |
|
I/O Panel
|
2 x USB 3.2 Gen 1 (USB 3.0), 1 x 3.5mm Audio Jack,1 x 3.5mm Mic Jack, 1x ARGB/PWM Hub (may depend on region and model) |
|
Pre-installed Fans – Front
|
3x 120mm 650~1800RPM SickleFlow PWM ARGB |
|
Pre-installed Fans – Rear
|
1x 120mm 1000-1400RPM MasterFan Lite |
|
Fan Support – Top
|
3x 120mm, 2x 140mm |
|
Fan Support – Front
|
3x 120mm, 2x 140mm |
|
Fan Support – Rear
|
1x 120mm |
|
Radiator Support – Top
|
120mm, 240mm, 360mm, (44mm max motherboard component height) |
|
Radiator Support – Front
|
120mm, 140mm, 240mm, 280mm, 360mm, (75mm clearance) |
|
Radiator Support – Rear
|
120mm |
|
Clearance – CPU Cooler
|
165mm / 6.49″ |
|
Clearance – PSU
|
180mm/7.08″ |
|
Clearance – GFX
|
410mm/16.1″ |
|
Cable Routing
|
19~27mm |
|
Dust Filters
|
Top, Front, Bottom |
|
Power Supply Support
|
Bottom Mount, ATX |
|
Warranty
|
2 years |
|
Model Number
|
MCB-B520-KGNN-RGA |
*Note: The actual colors may be different from the color displayed here. Features, Price and Specifications are subject to change without notice.
|
