Specifications: Specification Details Model Number HAF 700: H700-IGNN-S00, HAF 700 WHITE: H700-WGNN-S00 Exterior Colour Titanium Grey, White Materials – Exterior Steel, Plastic Materials – Left Side Panel Tempered Glass, Steel, Plastic Dimensions (L x W x
| Specification | Details |
|---|---|
| Model Number | HAF 700: H700-IGNN-S00, HAF 700 WHITE: H700-WGNN-S00 |
| Exterior Colour | Titanium Grey, White |
| Materials – Exterior | Steel, Plastic |
| Materials – Left Side Panel | Tempered Glass, Steel, Plastic |
| Dimensions (L x W x H) | 556 x 279 x 540 mm (Body Size) |
| Dimensions (L x W x H) | 666 x 291 x 626 mm (incl. Protrusions) |
| Motherboard Support | Mini-ITX, Micro-ATX, ATX, E-ATX, SSI-CEB, SSI-EEB |
| Expansion Slots | 8 |
| 2.5″ / 3.5″ Drive Bays (Combo) | 9 (4*HDD bracket, 5*Screw + Rubber) |
| I/O Panel – USB Ports | 1x USB 3.2 Gen 2 Type C, 4x USB 3.2 Gen 1 (3.0) |
| I/O Panel – Audio In / Out | 1x 3.5mm 4 Poles Audio Jack, 1x 3.5mm Mic Jack |
| Pre-installed Fans – Front | 2x SickleFlow 200 ARGB PWM |
| Pre-installed Fans – Rear | 2x SickleFlow 120 ARGB PWM |
| Pre-installed Fans – Bottom | 1x SickleFlow 120 ARGB PWM |
| Fan Support – Top | 2x 200mm, 3x 140mm, 6x 120mm (Remove 480mm bracket) |
| Fan Support – Front | 2x 200mm |
| Fan Support – Rear | 2x 120mm |
| Fan Support – Bottom | 3x 120/140mm |
| Fan Support – Side | 4x 120mm / 3x 140mm |
| Radiator Support – Top | Up to 2x 360mm / 1x 420mm |
| Radiator Support – Rear | Up to 240mm |
| Radiator Support – Bottom | Up to 420/360mm |
| Radiator Support – Side | Up to 480/420/360mm |
| Clearance – CPU Cooler | 166mm / 6.53″ |
| Clearance – PSU | 200mm / 7.87″ |
| Clearance – GFX | 490mm / 19.29″ |
| Cable Routing – Behind Motherboard Tray | 90-101mm |
| Included Accessories | 1x Rotatable Radiator Bracket, 1x LED Controller A1 (ARGB Gen2), 1x ARGB/PWM Hub |
| Dust Filters | Bottom, Right Side |
| Power Supply Support | Bottom Mount, ATX |
| Warranty | 2 years |
| Size | Full Tower |
| Series | HAF Series |
| Note** | * For regular 30mm thick radiators, for thicker please reference compatibility sheet. |
