Exterior Color White Materials – Outlook Steel, Mesh, Plastic Materials – Side Panel Tempered Glass, Steel Dimensions (L x W x H) 516 x 224 x 510mm (incl. Protrusions) Motherboard Support ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12″ x 14.1″, may imp
|
Exterior Color
|
White |
|
Materials – Outlook
|
Steel, Mesh, Plastic |
|
Materials – Side Panel
|
Tempered Glass, Steel |
|
Dimensions (L x W x H)
|
516 x 224 x 510mm (incl. Protrusions) |
|
Motherboard Support
|
ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12″ x 14.1″, may impact cable management and case features, remove cable cover and GPU fan bracket features) |
|
Expansion Slots
|
7 |
|
5.25″ Drive Bays
|
N/A |
|
2.5″ / 3.5″ Drive Bays (Combo)
|
2 |
|
2.5″ Drive Bays
|
2 |
|
I/O Panel
|
2x USB 3.2 Gen 1 (formerly USB 3.0), 1x USB 3.2 Gen 2 Type-C, 1x single Audio Jack, 1x Reset/ARGB button |
|
ARGB Controller
|
ARGB Hub |
|
Pre-installed Fans – Front
|
2x 200mm ARGB Fan |
|
Pre-installed Fans – Rear
|
1x 120mm SickleFlow PWM ARGB |
|
Pre-installed Fans – Top on HDD cage
|
1x 120mm SickleFlow PWM (GPU Fan) |
|
Fan Support – Top
|
3x 120mm, 2x 140mm, 2x 200mm |
|
Fan Support – Front
|
3x 120mm, 2x 140mm, 2x 200mm, *200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness |
|
Fan Support – Rear
|
1x 120mm |
|
Fan Support – Top on HDD cage
|
1x 120mm |
|
Radiator Support – Top
|
120mm, 140mm, 240mm, 280mm, 360mm |
|
Radiator Support – Front
|
120mm, 140mm, 200mm, 240mm, 280mm, 360mm |
|
Radiator Support – Rear
|
120mm |
|
Clearance – CPU Cooler
|
167mm/6.5″ |
|
Clearance – PSU
|
180mm/7.1″ |
|
Clearance – GFX
|
410mm/16.1″ |
|
Cable Routing – Behind Motherboard Tray
|
30mm |
|
Dust Filters
|
Top, Bottom |
|
Power Supply Support
|
Bottom Mount, ATX |
|
Warranty
|
2 years |
|
Series
|
HAF Series |
|
Size
|
Mid Tower |
*Note: The actual colors may be different from the color displayed here. Features, Price and Specifications are subject to change without notice.
|
Exterior Color
|
White |
|
Materials – Outlook
|
Steel, Mesh, Plastic |
|
Materials – Side Panel
|
Tempered Glass, Steel |
|
Dimensions (L x W x H)
|
516 x 224 x 510mm (incl. Protrusions) |
|
Motherboard Support
|
ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12″ x 14.1″, may impact cable management and case features, remove cable cover and GPU fan bracket features) |
|
Expansion Slots
|
7 |
|
5.25″ Drive Bays
|
N/A |
|
2.5″ / 3.5″ Drive Bays (Combo)
|
2 |
|
2.5″ Drive Bays
|
2 |
|
I/O Panel
|
2x USB 3.2 Gen 1 (formerly USB 3.0), 1x USB 3.2 Gen 2 Type-C, 1x single Audio Jack, 1x Reset/ARGB button |
|
ARGB Controller
|
ARGB Hub |
|
Pre-installed Fans – Front
|
2x 200mm ARGB Fan |
|
Pre-installed Fans – Rear
|
1x 120mm SickleFlow PWM ARGB |
|
Pre-installed Fans – Top on HDD cage
|
1x 120mm SickleFlow PWM (GPU Fan) |
|
Fan Support – Top
|
3x 120mm, 2x 140mm, 2x 200mm |
|
Fan Support – Front
|
3x 120mm, 2x 140mm, 2x 200mm, *200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness |
|
Fan Support – Rear
|
1x 120mm |
|
Fan Support – Top on HDD cage
|
1x 120mm |
|
Radiator Support – Top
|
120mm, 140mm, 240mm, 280mm, 360mm |
|
Radiator Support – Front
|
120mm, 140mm, 200mm, 240mm, 280mm, 360mm |
|
Radiator Support – Rear
|
120mm |
|
Clearance – CPU Cooler
|
167mm/6.5″ |
|
Clearance – PSU
|
180mm/7.1″ |
|
Clearance – GFX
|
410mm/16.1″ |
|
Cable Routing – Behind Motherboard Tray
|
30mm |
|
Dust Filters
|
Top, Bottom |
|
Power Supply Support
|
Bottom Mount, ATX |
|
Warranty
|
2 years |
|
Series
|
HAF Series |
|
Size
|
Mid Tower |
*Note: The actual colors may be different from the color displayed here. Features, Price and Specifications are subject to change without notice.
