Specifications Specification Details Model Mpe-C501-Afcag-3E** Atx Version Atx Rev. 3.1 Pfc Active Pfc Input Voltage 100-240V Input Current 15-7A Input Frequency 50-60Hz Dimensions (L X W X H) 180 X 150 X 86 Mm Fan Size 140Mm Fan Bearing Two Ball Bearing
| Specification | Details |
|---|---|
| Model | Mpe-C501-Afcag-3E** |
| Atx Version | Atx Rev. 3.1 |
| Pfc | Active Pfc |
| Input Voltage | 100-240V |
| Input Current | 15-7A |
| Input Frequency | 50-60Hz |
| Dimensions (L X W X H) | 180 X 150 X 86 Mm |
| Fan Size | 140Mm |
| Fan Bearing | Two Ball Bearing |
| Efficiency | ?90% @ Typical Load |
| 80 Plus Rating | 80 Plus Gold |
| Erp 2014 Lot 3 | Yes |
| Operating Temperature | 0-50°C |
| Power Good Signal | 100 – 150 Ms |
| Hold Up Time | ?16Ms At 100% Load |
| Mtbf | ≫100,000 Hours |
| Protections | Ovp / Opp / Scp / Ocp / Uvp / Otp / Inrush Protection |
| Regulatory | Tuv, Ctuvus, Ce, Fcc, Bsmi, Ccc, Eac, Rcm, Ukca, Bis |
| Atx 24 Pin Connectors | 1 |
| Eps 4+4 Pin Connectors | 1 |
| Eps 8 Pin Connector | 1 |
| Sata Connectors | 12 |
| Peripheral 4 Pin Connectors | 4 |
| Pci-E 6+2 Pin Connectors | 3 |
| 12V-2X6 Connectors | 1 |
| Series | Mwe Gold Series |
| Category | Above 750W |
| Modular | Fully Modular |
| 80 Plus Efficiency | Gold |
| Form Factor | Atx |
| Watts | 1250W |
