Specifications: Category Details Memory – Dual Channel DDR5 Memory Technology – 4 x DDR5 DIMM Slots – Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC)* – Max. capacity of system memory: 256GB – Supports Extreme Memory Profile (XMP) and EXTend
| Category | Details |
|---|---|
| Memory | – Dual Channel DDR5 Memory Technology – 4 x DDR5 DIMM Slots – Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC)* – Max. capacity of system memory: 256GB – Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules * Please refer to Memory Support List on ASRock’s website for more information. |
| CPU | – 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode* * PCIE1 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2) series processors. – 1 x PCIe 4.0 x16 Slot (PCIE2), supports x4 mode* – 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module |
| Expansion Slot | – Supports NVMe SSD as boot disks – Supports AMD CrossFire™ – 15μ Gold Contact in VGA PCIe Slot (PCIE1) |
| Graphics | – Integrated AMD RDNA™ graphics (Actual support may vary by CPU) – 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz – 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 30Hz* |
| Audio | – 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec) – Impedance Sensing on Rear Out port – Individual PCB Layers for R/L Audio Channel – Nahimic Audio |
| LAN | – 2.5 Gigabit LAN 10/100/1000/2500 Mb/s – Dragon RTL8125BG – Supports Dragon 2.5G LAN Software |
| Wireless LAN | – 802.11be 2×2 Wi-Fi 7 Module – Supports 2.4GHz/5GHz/6GHz* frequency band – Supports Bluetooth 5.4 |
| USB | – 2 x USB4 Type-C (Rear) – 2 x USB 3.2 Gen1 Type-A (Rear) – 1 x USB 3.2 Gen2x2 Type-C (Front) |
| Rear Panel I/O | – 1 x HDMI Port – 1 x Optical SPDIF Out Port – 1 x RJ-45 LAN Port – 1 x BIOS Flashback Button – 1 x Line Out Jack (Gold Audio Jack) |
| Storage | – Supports RAID 0 and RAID 1 for SATA storage devices – Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices* |
| Connector | – 1 x Thermistor Cable Header – 1 x Power LED and Speaker Header – 3 x Addressable LED Headers** |
| BIOS Feature | – 256Mb AMI UEFI Legal BIOS with GUI support – ASRock Motherboard Utility (A-Tuning) |
| Certifications | – Microsoft® Windows® OS 10 64-bit / 11 64-bit – FCC, CE – ErP/EuP ready |
| Accessories | – 2 x SATA Data Cables – 2 x ASRock WiFi 2.4/5/6 GHz Antennas |
| Platform | – ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm – 8 Layer PCB – Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors* |
| Colour | |
| Primary Colour | White |
| Back Connect | |
| Back Connect | No |
| Lighting | |
| Lighting | Yes |
| Water Cooling | |
| Watercooling | No |
| Motherboard | |
| Motherboard Chipset | AMD X870 |
| Dual BIOS | No |
| Wi-Fi & LAN | |
| LAN | Yes |
| LAN Ports | 1x 2.5 Gbit/s |
| Wi-Fi / Bluetooth | Yes |
| Form Factor | |
| Motherboard formfactor | ATX |
| External Ports | |
| USB4 Gen 3×2 (external) Type C | 2.0000 |
| USB 3.0 (external) Type A | 4 |
| USB 2.0 (external) Type A | 6 |
| Display Connectors | HDMI (1x), USB Type C (Display Port shared) (1x) |
| CPU | |
| CPU Manufacturer | AMD |
| CPU Socket | AM5 |
| Fan Header | |
| 4 pin fan connectors | 7 |
| Memory | |
| Max. Memory | 256 GB |
| Memory Type | DDR5 |
| Memory Form Factor | DIMM |
| Max. Memory Speed (OC) | 8000 MT/s |
| EEC Support | Yes |
| Memory slots | 4x |
| Expansion Slots | |
| PCIe x16 slots (total) | 2 |
| PCIe 5.0 x16 mechanical slot | 1 |
| PCIe 4.0 x4 mechanical slot | 1 |
| Internal Ports | |
| CPU Power Supply | 2x 8-Pin |
| RGB / LED connectors | 1x RGB (4-Pin 5050 12VGRB), 3x Digital RGB (3-Pin 5VDG) |
| USB 3.0 / 3.1 / 3.2 (internal) Type C Header | 1 |
| USB 3.0 / 3.1 / 3.2 (internal) Type C Possible Ports | 1 |
| USB 3.0 (internal) Header | 1 |
| USB 3.0 (internal) Possible Ports | 2 |
| USB 2.0 (internal) Header | 2 |
| USB 2.0 (internal) Possible Ports | 3 |
| Front Panel Audio Header | Yes |
| Storage Ports | |
| M.2 PCIe 3.0 x4 & SATA 6G | 1 |
| M.2 PCIe 4.0 x4 | 1 |
| M.2 PCIe 5.0 x4 | 1 |
| M.2 E-Key | 1 |
| SATA 6G (internal) | 4 |
| Cooling | |
| M.2 Heatsinks | Yes |
| Audio | |
| Soundchip | Realtek ALC1220 |
