Specifications: Feature Specification Unique Features Super Alloy, XXL Aluminum Heatsink, 50A Power Choke, Sapphire Black PCB, Hyper M.2 (PCIe Gen4x4), POST Status Checker, Full Spike Protection CPU Support AMD AM4 Ryzen 3000, 4000, 5000 series, 8 Power P
| Feature | Specification |
| Unique Features | Super Alloy, XXL Aluminum Heatsink, 50A Power Choke, Sapphire Black PCB, Hyper M.2 (PCIe Gen4x4), POST Status Checker, Full Spike Protection |
| CPU Support | AMD AM4 Ryzen 3000, 4000, 5000 series, 8 Power Phase Digi Power design |
| Chipset | AMD PRO565 |
| Memory | Dual-channel DDR4, 4 DIMM slots, up to 128GB, up to DDR4 4733+(OC) for APUs, 4533+(OC) for CPUs, ECC/non-ECC support |
| Graphics | Integrated AMD Radeon Vega Graphics, DirectX 12, HDMI 2.1 (4K @ 60Hz), 16GB max shared memory |
| Audio | 7.1 CH HD Audio, Realtek ALC1220 Codec, Blu-ray support, Surge Protection |
| LAN | Gigabit LAN (Realtek RTL8111H), Wake-On-LAN, Lightning/ESD Protection |
| Wireless | Intel 802.11ac WiFi, Dual-band 2.4/5 GHz, Bluetooth 4.2, speed up to 433 Mbps |
| Expansion Slots | 2 x PCIe x16 (Gen4/Gen3), 1 x PCIe x1, AMD Quad CrossFireX |
| Storage | 4 x SATA3 6Gb/s, 1 x Hyper M.2 (Gen4x4/Gen3x4) |
| I/O Ports (Rear) | 2 x Antenna Ports, 1 x PS/2 Mouse/Keyboard, 1 x HDMI, 4 x USB 3.2 Gen1, 2 x USB 2.0, 1 x RJ-45 LAN, Audio Jacks |
| Cooling | 1 x CPU Fan Connector, 3 x Chassis/Water Pump Fan Connectors, Smart Fan Control |
| Connectors | 1 x COM, 1 x SPI TPM, 2 x RGB LED, 2 x Addressable LED, 2 x USB 3.2 Gen1 Headers, 2 x USB 2.0 Headers, 24-pin ATX, 8-pin 12V |
| Form Factor | Micro ATX, 9.6″ x 9.6″, 2oz Copper PCB |
| Software | ASRock Utility (A-Tuning), Polychrome SYNC |
| BIOS | 256Mb UEFI, Plug and Play, ACPI 5.1, Jumperfree, Multi-Voltage Adjustment |
| OS Support | Windows 10/11 64-bit |
| Accessories | I/O Shield, 2 x SATA cables, 2 x WiFi Antennas, M.2 Screw |
| Feature | Specification |
| Unique Features | Super Alloy, XXL Aluminum Heatsink, 50A Power Choke, Sapphire Black PCB, Hyper M.2 (PCIe Gen4x4), POST Status Checker, Full Spike Protection |
| CPU Support | AMD AM4 Ryzen 3000, 4000, 5000 series, 8 Power Phase Digi Power design |
| Chipset | AMD PRO565 |
| Memory | Dual-channel DDR4, 4 DIMM slots, up to 128GB, up to DDR4 4733+(OC) for APUs, 4533+(OC) for CPUs, ECC/non-ECC support |
| Graphics | Integrated AMD Radeon Vega Graphics, DirectX 12, HDMI 2.1 (4K @ 60Hz), 16GB max shared memory |
| Audio | 7.1 CH HD Audio, Realtek ALC1220 Codec, Blu-ray support, Surge Protection |
| LAN | Gigabit LAN (Realtek RTL8111H), Wake-On-LAN, Lightning/ESD Protection |
| Wireless | Intel 802.11ac WiFi, Dual-band 2.4/5 GHz, Bluetooth 4.2, speed up to 433 Mbps |
| Expansion Slots | 2 x PCIe x16 (Gen4/Gen3), 1 x PCIe x1, AMD Quad CrossFireX |
| Storage | 4 x SATA3 6Gb/s, 1 x Hyper M.2 (Gen4x4/Gen3x4) |
| I/O Ports (Rear) | 2 x Antenna Ports, 1 x PS/2 Mouse/Keyboard, 1 x HDMI, 4 x USB 3.2 Gen1, 2 x USB 2.0, 1 x RJ-45 LAN, Audio Jacks |
| Cooling | 1 x CPU Fan Connector, 3 x Chassis/Water Pump Fan Connectors, Smart Fan Control |
| Connectors | 1 x COM, 1 x SPI TPM, 2 x RGB LED, 2 x Addressable LED, 2 x USB 3.2 Gen1 Headers, 2 x USB 2.0 Headers, 24-pin ATX, 8-pin 12V |
| Form Factor | Micro ATX, 9.6″ x 9.6″, 2oz Copper PCB |
| Software | ASRock Utility (A-Tuning), Polychrome SYNC |
| BIOS | 256Mb UEFI, Plug and Play, ACPI 5.1, Jumperfree, Multi-Voltage Adjustment |
| OS Support | Windows 10/11 64-bit |
| Accessories | I/O Shield, 2 x SATA cables, 2 x WiFi Antennas, M.2 Screw |
