| Case Specification |
| Dimensions |
406 x 206 x 450mm (DWH) |
| Form Factor |
Mid Tower |
| Materials |
Steel + Plastic |
| Mainboard Support |
E-ATX, ATX, Micro-ATX, ITX |
| Front Access & Controls |
Power, Reset, USB 2.0 x2, USB 3.0 x 1,Headphone/Mic Combo Jack |
| Side Panel |
Tempered glass |
|
| Expansion & Drive Bays |
| Expansion Slots |
7 |
| 3.5″ /2.5″ |
2/1 |
| 2.5″ |
2 |
|
| Fan Support |
| Front |
3 x 120 / 2 x 140mm |
| Top |
2 x 120 / 2 x 140mm |
| Power Supply Shroud |
2 x 120mm |
| Rear |
1 x 120mm |
| Included Fan(s) |
3 x 120mm fixed mode RGB fans in front & 1 x 120mm regular fan in rear (NX292 White)
3 x 120mm RGB fixed mode fans in front & 1 x 120mm RGB fixed mode fan in rear (NX292 Elite White) |
|
| Radiator Support |
| Front |
120 / 140 / 240 / 280 / 360mm |
| Rear |
120mm (Length ? 156mm) |
|
| Clearance |
| Max GPU Length |
? 320mm |
| Max CPU Cooler Height |
? 155mm |
| Max PSU Length |
? 165mm(with HDD)
? 300mm(without HDD) |
|
| Miscellaneous |
| Dust Filter |
Top / Bottom |
| Net Weight |
4.5KG (NX292 White) / 4.94 Kg (NX292 Elite White) |
| Gross Weight |
5.3KG (NX292 White) / 5.91 Kg (NX292 Elite White) |
| Warranty |
1 Year |
| UPC# |
0-761345-81008-1 (NX292 White)
0-761345-81039-5 (NX292 Elite White) |
|
