Amd
In Stock
₹36,323
Model 100-100000589Wof Platform Desktop Market Segment Enthusiast Desktop Product Family Amd Ryzen Processors Product Line Amd Ryzen 9 Desktop Processors Amd Pro Technologies No Consumer Use Yes Regional Availability Global Former Codename Raphael Am5 Ar
In Stock
In Stock
Additional information
| Model | 100-100000589Wof |
| Platform | Desktop |
| Market Segment | Enthusiast Desktop |
| Product Family | Amd Ryzen Processors |
| Product Line | Amd Ryzen 9 Desktop Processors |
| Amd Pro Technologies | No |
| Consumer Use | Yes |
| Regional Availability | Global |
| Former Codename | Raphael Am5 |
| Architecture | Zen 4 |
| # Of Cpu Cores | 12 |
| Multithreading (Smt) | Yes |
| # Of Threads | 24 |
| Max. Boost Clock | Up To 5.6Ghz |
| Base Clock | 4.7Ghz |
| L1 Cache | 768Kb |
| L2 Cache | 12Mb |
| L3 Cache | 64Mb |
| Default Tdp | 170W |
| Processor Technology For Cpu Cores | Tsmc 5Nm Finfet |
| Processor Technology For I/O Die | Tsmc 6Nm Finfet |
| Cpu Compute Die (Ccd) Size | 71Mm≤ |
| I/O Die (Iod) Size | 122Mm≤ |
| Package Die Count | 3 |
| Unlocked For Overclocking | Yes |
| Amd Expo Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| Amd Ryzen Master Support | Yes |
| Cpu Socket | Am5 |
| Supporting Chipsets | X670E |
| X670 | |
| B650E | |
| B650 | |
| Cpu Boost Technology | Precision Boost 2 |
| Instruction Set | X86-64 |
| Supported Extensions | Aes, Amd-V, Avx, Avx2, Avx512, Fma3, Mmx(+), Sha, Sse, Sse2, Sse3, Sse4.1, Sse4.2, Sse4A, Ssse3, X86-64 |
| Thermal Solution (Pib) | Not Included |
| Max. Operating Temperature (Tjmax) | 95∞C |
| Os Support | Windows 11 – 64-Bit Edition |
| Windows 10 – 64-Bit Edition | |
| Rhel X86 64-Bit | |
| Ubuntu X86 64-Bit | |
| *Operating System (Os) Support Will Vary By Manufacturer. | |
| Connectivity | |
| Usb Type-C Support | Yes |
| Native Usb 3.2 Gen 2 (10Gbps) Ports | 4 |
| Native Usb 3.2 Gen 1 (5Gbps) Ports | 0 |
| Native Usb 2.0 (480Mbps) Ports | 1 |
| Native Sata Ports | 0 |
| Native Pcie Lanes (Total/Usable) | 28/24 |
| Additional Usable Pcie Lanes From Motherboard | Amd X670E 12X Gen4 |
| Amd X670 12X Gen4 | |
| Amd B650E 8X Gen4 | |
| Amd B650 8X Gen4 | |
| Nvme Support | Boot, Raid0, Raid1, Raid10 |
| Memory Channels | 2 |
| Max. Memory | 128Gb |
| System Memory Subtype | Udimm |
| Max Memory Speed | 1X1R 5200 Mt/S |
| 1X2R 5200 Mt/S | |
| 2X1R 3600 Mt/S | |
| 2X2R 3600 Mt/S | |
| Ecc Support | Yes (Requires Mobo Support) |
| Graphics Capabilities | |
| Integrated Graphics | Yes |
| Graphics Model | Amd Radeon Graphics |
| Graphics Core Count | 2 |
| Graphics Frequency | 2200 Mhz |
| Gpu Base | 400 Mhz |
| Usb Type-C Displayport Alternate Mode | Yes |
| Key Features | |
| Supported Technologies | Amd Expo Technology |
| Amd Ryzen Technologies | |
| Warranty | 3 Years |
*Note: The Actual Colors May Be Different From The Color Displayed Here. Features, Price And Specifications Are Subject To Change Without Notice.
Description
| Model | 100-100000589Wof |
| Platform | Desktop |
| Market Segment | Enthusiast Desktop |
| Product Family | Amd Ryzen Processors |
| Product Line | Amd Ryzen 9 Desktop Processors |
| Amd Pro Technologies | No |
| Consumer Use | Yes |
| Regional Availability | Global |
| Former Codename | Raphael Am5 |
| Architecture | Zen 4 |
| # Of Cpu Cores | 12 |
| Multithreading (Smt) | Yes |
| # Of Threads | 24 |
| Max. Boost Clock | Up To 5.6Ghz |
| Base Clock | 4.7Ghz |
| L1 Cache | 768Kb |
| L2 Cache | 12Mb |
| L3 Cache | 64Mb |
| Default Tdp | 170W |
| Processor Technology For Cpu Cores | Tsmc 5Nm Finfet |
| Processor Technology For I/O Die | Tsmc 6Nm Finfet |
| Cpu Compute Die (Ccd) Size | 71Mm≤ |
| I/O Die (Iod) Size | 122Mm≤ |
| Package Die Count | 3 |
| Unlocked For Overclocking | Yes |
| Amd Expo Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| Amd Ryzen Master Support | Yes |
| Cpu Socket | Am5 |
| Supporting Chipsets | X670E |
| X670 | |
| B650E | |
| B650 | |
| Cpu Boost Technology | Precision Boost 2 |
| Instruction Set | X86-64 |
| Supported Extensions | Aes, Amd-V, Avx, Avx2, Avx512, Fma3, Mmx(+), Sha, Sse, Sse2, Sse3, Sse4.1, Sse4.2, Sse4A, Ssse3, X86-64 |
| Thermal Solution (Pib) | Not Included |
| Max. Operating Temperature (Tjmax) | 95∞C |
| Os Support | Windows 11 – 64-Bit Edition |
| Windows 10 – 64-Bit Edition | |
| Rhel X86 64-Bit | |
| Ubuntu X86 64-Bit | |
| *Operating System (Os) Support Will Vary By Manufacturer. | |
| Connectivity | |
| Usb Type-C Support | Yes |
| Native Usb 3.2 Gen 2 (10Gbps) Ports | 4 |
| Native Usb 3.2 Gen 1 (5Gbps) Ports | 0 |
| Native Usb 2.0 (480Mbps) Ports | 1 |
| Native Sata Ports | 0 |
| Native Pcie Lanes (Total/Usable) | 28/24 |
| Additional Usable Pcie Lanes From Motherboard | Amd X670E 12X Gen4 |
| Amd X670 12X Gen4 | |
| Amd B650E 8X Gen4 | |
| Amd B650 8X Gen4 | |
| Nvme Support | Boot, Raid0, Raid1, Raid10 |
| Memory Channels | 2 |
| Max. Memory | 128Gb |
| System Memory Subtype | Udimm |
| Max Memory Speed | 1X1R 5200 Mt/S |
| 1X2R 5200 Mt/S | |
| 2X1R 3600 Mt/S | |
| 2X2R 3600 Mt/S | |
| Ecc Support | Yes (Requires Mobo Support) |
| Graphics Capabilities | |
| Integrated Graphics | Yes |
| Graphics Model | Amd Radeon Graphics |
| Graphics Core Count | 2 |
| Graphics Frequency | 2200 Mhz |
| Gpu Base | 400 Mhz |
| Usb Type-C Displayport Alternate Mode | Yes |
| Key Features | |
| Supported Technologies | Amd Expo Technology |
| Amd Ryzen Technologies | |
| Warranty | 3 Years |
*Note: The Actual Colors May Be Different From The Color Displayed Here. Features, Price And Specifications Are Subject To Change Without Notice.
Reviews
There are no reviews yet.
