Features GPU: Boost Clock: Up to 3290 MHz GPU: Game Clock: Up to 2700 MHz Memory: 16GB/128 bit DDR6. 20Gbps Effective Stream Processors: 2048 AMD RDNA™ 4 Architecture Ray Accelerator: 32 Warranty: 3 Years Specifications GPU AMD Radeon™ RX 9060 XT Graphics
| GPU |
AMD Radeon™ RX 9060 XT Graphics Card
|
| AMD RDNA™ 4 Architecture | |
|
Engine Clock
|
Boost Clock: Up to 3290 MHz
|
| Game Clock: Up to 2700 MHz | |
|
Stream Processors
|
2048
|
|
Compute Units
|
32 CUs (3rd Gen RT + 2nd Gen AI Accelerators)
|
|
Infinity Cache
|
32MB
|
|
Ray Accelerators
|
32
|
|
AI Accelerator
|
64
|
|
Memory Size/Bus
|
16GB/128 bit GDDR6
|
|
Memory Clock
|
20 Gbps Effective
|
|
Displays
|
Maximum 3 Displays
|
|
Resolution
|
HDMI®: 7680×4320
|
| DisplayPort™ 2.1a: 7680×4320 | |
|
Interface
|
PCI-Express 5.0 x16
|
|
Output
|
2x HDMI®
|
| 1x DisplayPort™ 2.1a | |
|
BIOS Support
|
UEFI
|
|
Game Index
|
1440P
|
|
Sapphire Features
|
Honeywell PTM7950 Thermal Interface Material (TIM)
|
| AeroCurve Fan Blade | |
| Free Flow | |
| FrameDefense | |
| Integrated Cooling Module | |
| Dual-X Cooling Technology | |
| High TG Copper PCB | |
| Optimized Composite Heatpipes | |
| Metal Backplate | |
| 9-Phase Digital Power Design | |
| Fuse Protection | |
| Intelligent Fan Control | |
| Precision Fan Control | |
| TriXX Supported | |
| TriXX Boost | |
|
AMD Features
|
AMD RDNA™ 4 Architecture
|
| 32 Compute Units (3rd Gen RT + 2nd Gen AI Accelerators) | |
| AMD HYPR-RX with AFMF 2 | |
| AMD FidelityFX™ Super Resolution 4 with AI Upscaling | |
| DisplayPort™ 2.1a | |
| AMD Radiance Display™ Engine | |
| AMD Fluid Motion Frames 2 technology | |
| AMD Radeon™ Anti-Lag 2 technology | |
| AV1 Encode/Decode | |
| AMD FidelityFX™ technologies | |
| Microsoft® DirectX® 12 Ultimate | |
| AMD Noise Suppression | |
| AMD Freesync™ technology | |
| AMD Infinity Cache | |
| 16 GB of GDDR6 on 128-bit Memory Bus | |
| AMD smart technologies | |
| AMD Software: Adrenalin Edition™ application | |
|
Cooler Type
|
Dual-X Cooling
|
| AeroCurve Fan Blade | |
| Free Flow | Integrated Cooling Module |
| High TG Copper PCB | |
| Optimized Composite Heatpipes | |
| Sleeve Bearing | |
|
Form Factor
|
2.3 slot, ATX
|
| Dimension: 240(L)X 124(W)X 46.1 (H)mm | |
|
Power Consumption
|
170W Typical Board Power
|
|
OS
|
Linux®, Windows® 10, and Windows 11. 64-bit operating system required
|
|
System Requirement
|
Minimum 450 Watt Power Supply
|
| 1 x 8-pin Power Connector. | |
| PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. | |
| Minimum 8GB of system memory. 16GB recommended. |
